Sick SIG350-0006AP100
Network devices | SIG350 | SIG350-0006AP100 | Product category: IO-Link Master | Communication interface: IO-LinkEthernetEtherCAT®REST APIMQTTOPC UA | Supported products: IO-Link DevicesBinary switchi…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Network devices | SIG350 | SIG350-0006AP100 | Product category: IO-Link Master | Communication interface: IO-LinkEthernetEtherCAT®REST APIMQTTOPC UA | Supported products: IO-Link DevicesBinary switching sensorsBinary actuators | Scope of delivery: SIG350-0006AP100Marking labelsQuickstart | Further functions: Web server integratedIIoT interface available (dual talk)
Specification
Features
| Product category | IO-Link Master |
|---|---|
| Supported products | IO-Link DevicesBinary switching sensorsBinary actuators |
| Further functions | Web server integratedIIoT interface available (dual talk) |
| Items supplied | SIG350-0006AP100, Marking labels, quickstart |
Mechanics/electronics
| IO-Link | 8 x M12, 5-pin female connector, A-coded |
|---|---|
| Power | 1 x M12, 5-pin male connector, L-coded1 x M12, 5-pin female connector, L-coded |
| Ethernet | 2 x M12, 4-pin female connector, D-coded |
| Supply voltage | 18Â VÂ DCÂ ... 30Â VÂ DCÂ 1) |
| Current carrying capacity (PWR1, PWR2) max. | â¤Â 16 A, US 2) |
| Current consumption | â¤Â 180 mA 3) |
| Total current (S1 ... S8) | â¤Â 10 A 2) |
| Voltage supply (pin 1) | 2Â A |
| Output current (DO) (pin 2Â + pin 4) | 2Â A |
| Current carrying capacity per port max. | 4Â A |
| Total current (S1 ... S8) | â¤Â 10 A 2) |
| Voltage supply (pin 2) | 2Â A |
| Current carrying capacity per port max. | 4Â A |
| Number | 16, configurable |
| Input characteristics | ENÂ 61131-2Â type 1Â and type 3 |
| Type | PNP |
| Filter time | 0 ms ... 15 ms |
| Delay time at signal change | 2 ms ... 5 ms |
| Circuit protection | Short-circuit protected (MOSFET with current measurement) |
| Number | 16, configurable |
| Type | PNP |
| Switching frequency | â¤Â 50 Hz |
| Circuit protection | Short-circuit protected (MOSFET with current measurement) |
| Optical indicators | 8Â LED green/yellow/red (Communication pin 4)8Â LED yellow/red (Communication pin 2)1Â LED green/red (device status)1Â LED green/yellow (Network status)1Â LED green (PLC operational status)1Â LED red (PLC configuration)3Â LED green (PLC configuration)2Â LED green/red (power supply) |
| Enclosure rating | IP67 (In fastened condition) |
| Protection class | IIIÂ 4) |
| Contamination rating | 2 |
| Housing material | Plastic (Valox 553) |
| Housing color | Dark gray |
| Weight | 486Â g |
| Dimensions (L x W x H) | 225 mm x 63 mm x 37.4 mm |
| UL File No. | E238799 |
Communication interface
| IO-Link | â |
|---|---|
| Remark | V1.1 |
| Number of ports | 8Â Â |
| Port Class | A/BÂ 1) |
| Data transmission rate | COM1, COM2, COM3 |
| Additional features | Data Storage |
| Ethernet | â |
| Remark | EoE (Ethernet over EtherCAT®) |
| EtherCAT® | â |
| Remark | TCP/IP |
| Number of ports | 2Â Â |
| Data transmission rate | 10/100Â MBit/s |
| Conformity class | C |
| Cycle time | â¥Â 250 µs |
| Addressing | Auto-increment, fixed addressing (rotary switch: static EtherCAT address (0-99)) |
| Factory setting | Static IPÂ address 0.0.0.0, DHCP client not activated |
| REST API | â |
| Remark | EoE (Ethernet over EtherCAT®) |
| Specification | JSON integration for IO-Link version (V1.0.0) |
| MQTT | â |
| Remark | EoE (Ethernet over EtherCAT®) |
| Specification | JSON integration for IO-Link version (V1.0.0) |
| OPC UA | â |
| Remark | EoE (Ethernet over EtherCAT®) |
| Specification | IO-Link Companion Specification Version (V1.0) |
| Operator interfaces | Integrated web server (a suitable EtherCAT PLC is required to activate the web server) |
Ambient data
| Ambient operating temperature | â25 °C ... +70 °C 1) |
|---|---|
| Ambient temperature, storage | â40 °C ... +80 °C 1) |
| Electromagnetic compatibility (EMC) | ENÂ 61000-6-2:2016 / ENÂ 61000-6-4:2020 |
| Shock load | ENÂ 60068-2-27 |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| ACMA declaration of conformity | â |
| China RoHS | â |
| cULus certificate | â |
Classifications
| ECLASS 5.0 | 27242208 |
|---|---|
| ECLASS 5.1.4 | 27242608 |
| ECLASS 6.0 | 27242608 |
| ECLASS 6.2 | 27242608 |
| ECLASS 7.0 | 27242608 |
| ECLASS 8.0 | 27242608 |
| ECLASS 8.1 | 27242608 |
| ECLASS 9.0 | 27242608 |
| ECLASS 10.0 | 27242608 |
| ECLASS 11.0 | 27242608 |
| ECLASS 12.0 | 27242608 |
| ETIM 5.0 | EC001604 |
| ETIM 6.0 | EC001604 |
| ETIM 7.0 | EC001604 |
| ETIM 8.0 | EC001604 |
| UNSPSC 16.0901 | 32151705 |
