Sick SIG350-0005AP100
Network devices | SIG350 | SIG350-0005AP100 | Product category: IO-Link Master | Communication interface: IO-LinkEthernetEtherNet/IP™REST APIMQTTOPC UA | Supported products: IO-Link DevicesBinary swit…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Network devices | SIG350 | SIG350-0005AP100 | Product category: IO-Link Master | Communication interface: IO-LinkEthernetEtherNet/IP™REST APIMQTTOPC UA | Supported products: IO-Link DevicesBinary switching sensorsBinary actuators | Scope of delivery: SIG350-0005AP100Marking labelsQuickstart | Further functions: Web server integratedIIoT interface available (dual talk)
Specification
Features
| Product category | IO-Link Master |
|---|---|
| Supported products | IO-Link DevicesBinary switching sensorsBinary actuators |
| Further functions | Web server integratedIIoT interface available (dual talk) |
| Items supplied | SIG350-0005AP100, Marking labels, quickstart |
Mechanics/electronics
| IO-Link | 8 x M12, 5-pin female connector, A-coded |
|---|---|
| Power | 1 x M12, 5-pin male connector, L-coded1 x M12, 5-pin female connector, L-coded |
| Ethernet | 2 x M12, 4-pin female connector, D-coded |
| Supply voltage | 18Ă‚ VĂ‚ DCĂ‚ ... 30Ă‚ VĂ‚ DCĂ‚ 1) |
| Current carrying capacity (PWR1, PWR2) max. | ≤ 16 A, US 2) |
| Current consumption | ≤ 180 mA 3) |
| Total current (S1 ... S8) | ≤ 10 A 2) |
| Voltage supply (pin 1) | 2Ă‚ A |
| Output current (DO) (pin 2Ă‚ + pin 4) | 2Ă‚ A |
| Current carrying capacity per port max. | 4Ă‚ A |
| Total current (S1 ... S8) | ≤ 10 A 2) |
| Voltage supply (pin 2) | 2Ă‚ A |
| Current carrying capacity per port max. | 4Ă‚ A |
| Number | 16, configurable |
| Input characteristics | ENĂ‚ 61131-2Ă‚ type 1Ă‚ and type 3 |
| Type | PNP |
| Filter time | 0 ms ... 15 ms |
| Delay time at signal change | 2 ms ... 5 ms |
| Circuit protection | Short-circuit protected (MOSFET with current measurement) |
| Number | 16, configurable |
| Type | PNP |
| Switching frequency | ≤ 50 Hz |
| Circuit protection | Short-circuit protected (MOSFET with current measurement) |
| Optical indicators | 8Ă‚ LED green/yellow/red (Communication pin 4)8Ă‚ LED yellow/red (Communication pin 2)1Ă‚ LED green/red (device status)1Ă‚ LED green/yellow (Network status)1Ă‚ LED green (PLC operational status)1Ă‚ LED red (PLC configuration)3Ă‚ LED green (PLC configuration)2Ă‚ LED green/red (power supply) |
| Enclosure rating | IP67 (In fastened condition) |
| Protection class | IIIĂ‚ 4) |
| Contamination rating | 2 |
| Housing material | Plastic (Valox 553) |
| Housing color | Dark gray |
| Weight | 486Ă‚ g |
| Dimensions (L x W x H) | 225 mm x 63 mm x 37.4 mm |
| UL File No. | E238799 |
Communication interface
| IO-Link | ✔ |
|---|---|
| Remark | V1.1 |
| Number of ports | 8 |
| Port Class | A/BĂ‚ 1) |
| Data transmission rate | COM1, COM2, COM3 |
| Additional features | Data Storage |
| Ethernet | ✔ |
| Remark | TCP/IP |
| EtherNet/IP™ | ✔ |
| Remark | TCP/IP |
| Number of ports | 2 |
| Data transmission rate | 10/100Ă‚ MBit/s |
| Additional features | Quick connect |
| Conformity class | C |
| Cycle time | ≥ 1 ms |
| Addressing | BOOTP, DHCP, rotary switch |
| Factory setting | Static IPĂ‚ address |
| REST API | ✔ |
| Specification | JSON integration for IO-Link version (V1.0.0) |
| MQTT | ✔ |
| Specification | JSON integration for IO-Link version (V1.0.0) |
| OPC UA | ✔ |
| Specification | IO-Link Companion Specification Version (V1.0) |
| Operator interfaces | Web server integrated |
Ambient data
| Ambient operating temperature | –25 °C ... +70 °C 1) |
|---|---|
| Ambient temperature, storage | –40 °C ... +80 °C 1) |
| Electromagnetic compatibility (EMC) | ENĂ‚ 61000-6-2:2016 / ENĂ‚ 61000-6-4:2020 |
| Shock load | ENĂ‚ 60068-2-27 |
Certificates
| EU declaration of conformity | ✔ |
|---|---|
| UK declaration of conformity | ✔ |
| ACMA declaration of conformity | ✔ |
| China RoHS | ✔ |
| cULus certificate | ✔ |
Classifications
| ECLASS 5.0 | 27242208 |
|---|---|
| ECLASS 5.1.4 | 27242608 |
| ECLASS 6.0 | 27242608 |
| ECLASS 6.2 | 27242608 |
| ECLASS 7.0 | 27242608 |
| ECLASS 8.0 | 27242608 |
| ECLASS 8.1 | 27242608 |
| ECLASS 9.0 | 27242608 |
| ECLASS 10.0 | 27242608 |
| ECLASS 11.0 | 27242608 |
| ECLASS 12.0 | 27242608 |
| ETIM 5.0 | EC001604 |
| ETIM 6.0 | EC001604 |
| ETIM 7.0 | EC001604 |
| ETIM 8.0 | EC001604 |
| UNSPSC 16.0901 | 32151705 |
