Sick SAPPC2D-08XS002
Safety systems | Safe Robotics Area Protection | SAPPC2D-08XS002 | Variant: sBot Speed CIP | Product type: Software | Robot controller: FANUC: R-30iB Plus | Stopping process of the robot: With speed r…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Safety systems | Safe Robotics Area Protection | SAPPC2D-08XS002 | Variant: sBot Speed CIP | Product type: Software | Robot controller: FANUC: R-30iB Plus | Stopping process of the robot: With speed reduction | Robot restart: Automatic | Safety controller type: Programmable | Interface: EtherNet/IP™ CIP Safety™
Specification
Features
| Variant | sBot Speed CIP |
|---|---|
| Product type | Software |
| Robot controller | FANUC: R-30iB Plus |
| Stopping process of the robot | With speed reduction |
| Robot restart | Automatic |
| Communication interface | EtherNet/IP⢠CIP Safety⢠|
| Safe state in the event of a fault | The safety outputs via the network are logic 0. |
| Safety task | Hazardous area protection |
| Safety controller type | Programmable |
| Performance level | PL d (ISO 13849-1) |
| Items supplied | Software (Safety Designer project file with functional logic, pre-configuration file for microScan3 Core EFI-pro, CIPÂ Safety communication setting and FANUC-specific settings) as well as operating instructions, connection diagram and SISTEMA file |
Functions
| Shut down in the event of an emergency situation | â |
|---|---|
| Prevent unexpected restarting after an emergency stop | â |
| Automated reset and restart with safe sequence monitoring | â |
| Optional manual reset | â |
| Trigger safety-rated monitored speed | â |
| Operating mode selection (implemented in robot control) | â |
| Enabling device - manual operating mode (implemented in robot control) | â |
Certificates
| China RoHS | â |
|---|
Classifications
| ECLASS 5.0 | 27279090 |
|---|---|
| ECLASS 5.1.4 | 27279090 |
| ECLASS 6.0 | 27279090 |
| ECLASS 6.2 | 27279090 |
| ECLASS 7.0 | 27279090 |
| ECLASS 8.0 | 27279090 |
| ECLASS 8.1 | 27279090 |
| ECLASS 9.0 | 27279090 |
| ECLASS 10.0 | 27279090 |
| ECLASS 11.0 | 27279090 |
| ECLASS 12.0 | 27279090 |
| ETIM 5.0 | EC001449 |
| ETIM 6.0 | EC001449 |
| ETIM 7.0 | EC001449 |
| ETIM 8.0 | EC001449 |
| UNSPSC 16.0901 | 32151705 |
