Sick RFH510-1004301
RFID | RFH5xx | RFH510-1004301 | Radio approval: European Union, USA, Canada, Australia, Korea, México, China, India, United Kingdom, Singapore | Frequency band: HF (13.56 MHz) | Reading range: ≤ 60 m…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
RFID | RFH5xx | RFH510-1004301 | Radio approval: European Union, USA, Canada, Australia, Korea, México, China, India, United Kingdom, Singapore | Frequency band: HF (13.56 MHz) | Reading range: ≤ 60 mm | Enclosure rating: IP67
Specification
Features
| Version | Short Range |
|---|---|
| Product category | RFID read/write device with integrated antenna |
| Radio approval | European Union 1)USACanadaAustraliaKoreaMéxicoChinaIndiaUnited KingdomSingapore |
| Frequency band | HF (13.56Â MHz) |
| Carrier frequency | 13.56Â MHz |
| RFID standard | ISO/IECÂ 15693, ISO/IECÂ 18000-3 âMode 1â |
| Connection type | IO-Link |
| Reading range | â¤Â 60 mm 2) |
| Antenna | Integrated |
| Air interface data transmission rate | 26Â kbit/s |
Mechanics/electronics
| Connection type | 1Â x M12, 4-pin male connector |
|---|---|
| Supply voltage | 11Â VÂ DCÂ ... 32Â VÂ DC |
| Power consumption | â¤Â 1.8 W |
| Housing material | Brass (chromium-plated)PBTP (blue) |
| Enclosure rating | IP67 |
| Protection class | II |
| Weight | 87Â g, Including nuts |
| Diameter | 30Â mm |
| Design | Cylindrical (M30) |
| MTTF | > 756 years 1) |
Interfaces
| IO-Link | â , IO-Link V1.1 |
|---|---|
| Remark | Process data length: IN (input), 32Â bytes; OUT (output), 32Â bytes |
| Function | Process data, parameterization, diagnosis |
| Data transmission rate | COM3 (230,4Â kBaud) |
| Digital outputs | 1Â (Q2, Switching, PNP, in IO-Link mode)2Â (Q1, Q2, Switching, PNP, in SIO mode) |
| Optical indicators | 4Â LEDs, multi-color (Process feedback) |
| Configuration software | PLC softwareSOPAS ETÂ 1) |
Ambient data
| Electromagnetic compatibility (EMC) | ENÂ 301489-3 V1.6.1Â (2013) |
|---|---|
| Vibration resistance | IECÂ 60068-2-6:2007-12 (10Â Hz to 55Â Hz / 1Â min / 5Â min) |
| Shock resistance | IECÂ 60068-2-27:2008-02 (30Â gn / 11Â ms / half-sine) |
| Ambient operating temperature | â25 °C ... +80 °C |
| Storage temperature | â25 °C ... +80 °C |
| Permissible relative humidity | 0%Â ... 95%, non-condensing |
Classifications
| ECLASS 5.0 | 27280401 |
|---|---|
| ECLASS 5.1.4 | 27280401 |
| ECLASS 6.0 | 27280401 |
| ECLASS 6.2 | 27280401 |
| ECLASS 7.0 | 27280401 |
| ECLASS 8.0 | 27280401 |
| ECLASS 8.1 | 27280401 |
| ECLASS 9.0 | 27280401 |
| ECLASS 10.0 | 27280401 |
| ECLASS 11.0 | 27280401 |
| ECLASS 12.0 | 27280401 |
| ETIM 6.0 | EC002998 |
| ETIM 7.0 | EC002998 |
| ETIM 8.0 | EC002998 |
| UNSPSC 16.0901 | 52161523 |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| ACMA declaration of conformity | â |
| China RoHS | â |
| cULus certificate | â |
| FCC certificate | â |
| Radio Approval certificate India | â |
| Radio Approval certificate Korea | â |
| Radio Approval certificate Mexico | â |
| Information according to Art. 3 of Data Act (Regulation EU 2023/2854) | â |
