Sick OLS20-BB1118342
Contrast sensors | OLS | OLS20-BB1118342 | Communication interface: IO-Link, Modbus | Light source: LED | Sensing distance: 100 mm | Sensing distance tolerance: ± 10 mm | Switching output: Push-pull:…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Contrast sensors | OLS | OLS20-BB1118342 | Communication interface: IO-Link, Modbus | Light source: LED | Sensing distance: 100 mm | Sensing distance tolerance: ± 10 mm | Switching output: Push-pull: PNP/NPN | Light spot size: 180 mm x 9 mm | Bar code types: 2/5 Interleaved with checksum | Track color: Orange | Connection type Detail: Plug, M12, 5-pin | Enclosure rating: IP67 | Housing material: Metal
Specification
Features
| Dimensions (W x H x D) | 31 mm x 62 mm x 52.5 mm |
|---|---|
| Sensing distance | ⤠100 mm |
| Sensing distance tolerance | ± 10 mm |
| Housing design | Rectangular |
| Working range | 90 mm ... 110 mm |
| Light source | LED, blue 1) |
| Wave length | 450Â nm |
| Light spot size | 180 mm x 9 mm 2) |
| Receiving filters | ⤠610 nm |
| Bar code types | 2/5 Interleaved with checksum |
| Module width (min.) | â¥Â 1.5 mm |
| Line radius (min.) | â¥Â 0.5 m |
| Track color | Orange |
| MTTFD | 271Â years |
Interfaces
| IO-Link | â , COM3 (230,4Â kBaud) |
|---|---|
| Cycle time | 5Â ms |
| Process data length | 21Â Byte Process Data In |
| Modbus | â , RTU RS-485 |
| Digital output | Q1 |
| Number | 1 |
Electronics
| Supply voltage | 18Â VÂ DCÂ ... 30Â VÂ DCÂ 1) |
|---|---|
| Ripple | â¤Â 5 Vpp 2) |
| Power consumption | <Â 3Â WÂ 3) |
| Sampling rate | 5Â ms |
| Accuracy optical center | ± 1 mm |
| Switching output | Push-pull: PNP/NPN |
| Switching output (voltage) | Push-pull: PNP/NPN HIGH = UV - 3 V/LOW ⤠3 V |
| Output current Imax. | <Â 100Â mA |
| Time delay | None |
| Protection class | III |
| Circuit protection | UV connections, reverse polarity protectedOutput Q short-circuit protectedInterference pulse suppression |
| LED risk group | 2 (IECÂ 62471) |
Mechanics
| Housing material | Zinc diecast |
|---|---|
| Connection type | Plug, M12, 5-pin |
| Weight | 250Â g |
Ambient data
| Ambient operating temperature | â10 °C ... +55 °C |
|---|---|
| Ambient temperature, storage | â25 °C ... +75 °C |
| Ambient light immunity | 50,000Â lx |
| Shock load | According to IECÂ 60068 |
| Enclosure rating | IP67 |
| UL File No. | NRKH.E181493 & NRKH7.E181493 |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| ACMA declaration of conformity | â |
| Moroccan declaration of conformity | â |
| China RoHS | â |
| cULus certificate | â |
| IO-Link certificate | â |
| Photobiological safety (IEC EN 62471) | â |
| Information according to Art. 3 of Data Act (Regulation EU 2023/2854) | â |
Classifications
| ECLASS 5.0 | 27270906 |
|---|---|
| ECLASS 5.1.4 | 27270906 |
| ECLASS 6.0 | 27270906 |
| ECLASS 6.2 | 27270906 |
| ECLASS 7.0 | 27270906 |
| ECLASS 8.0 | 27270906 |
| ECLASS 8.1 | 27270906 |
| ECLASS 9.0 | 27270906 |
| ECLASS 10.0 | 27270906 |
| ECLASS 11.0 | 27270906 |
| ECLASS 12.0 | 27270906 |
| ETIM 5.0 | EC001820 |
| ETIM 6.0 | EC001820 |
| ETIM 7.0 | EC001820 |
| ETIM 8.0 | EC001820 |
| UNSPSC 16.0901 | 39121528 |
