Sick LED light
Signal transmitters | Optical signal transmitters | LED light | Description: LED light for visually indicating the sensor status, e.g., muting status or ADO
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Signal transmitters | Optical signal transmitters | LED light | Description: LED light for visually indicating the sensor status, e.g., muting status or ADO
Specification
Features
| Product segment | Signal transmitters |
|---|---|
| Product | Optical signal transmitters |
| Description | LED light for visually indicating the sensor status, e.g., muting status or ADO |
| Material | ABS/PC |
| Electrical connection | 3 x Terminals 1) |
| Light up permanently | X0, X1 |
| Flash | X0, X2 |
| Permitted cross-section | Min: 0.25 mm² / 24 AWG, Max: 1.5 mm² / 16 AWG |
| Display | Orange LED |
| Operating voltage | 21.6Â VÂ AC/DCÂ ... 26.4Â VÂ AC/DC, 24Â VÂ AC/DC |
| Ambient operating temperature | –30 °C ... +60 °C |
| Enclosure rating mechanic | IP66 |
| Housing color | Orange, gray |
| Length | 85Â mm |
| Diameter | 62Â mm |
Certificates
| EU declaration of conformity | ✔ |
|---|
