Sick KTX-WS91142242ZZZZ
Contrast sensors | KTX | KTX-WS91142242ZZZZ | Light source: LED, RGB | Communication interface: – | Device type: Standard | Sensing distance: 13 mm | Switching output: PNP, NPN | Light spot size: 0.9…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Contrast sensors | KTX | KTX-WS91142242ZZZZ | Light source: LED, RGB | Communication interface: – | Device type: Standard | Sensing distance: 13 mm | Switching output: PNP, NPN | Light spot size: 0.9 mm x 3.8 mm | Light spot direction: Vertical | Light emission: Short device side | Connection type Detail: Male connector M12, 4-pin | Teach-in mode: 1-point teach-in, 2-point teach-in, teach-in dynamic, auto mode | Delivery status: 2-point teach-in | Housing material: Plastic
Specification
Features
| Special applications | Standard |
|---|---|
| Device type | Standard |
| Dimensions (W x H x D) | 30 mm x 53 mm x 78.5 mm |
| Sensing distance | ⤠13 mm |
| Sensing distance tolerance | ± 5 mm |
| Housing design | Large |
| Light source | LED, RGBÂ 1) |
| Wave length | 470Â nm, 525Â nm, 625Â nm |
| Light emission | Short device side |
| Light spot size | 0.9 mm x 3.8 mm |
| Light spot direction | Vertical 2) |
| Receiving filters | None |
| Teach-in mode | 1-point teach-in, 2-point teach-in, teach-in dynamic, auto mode |
| Output function | Light/dark switching |
| Delay time | Adjustable |
| Delivery status | 2-point teach-in |
| Parameter presettings | None |
| Setting the key lock | Standard |
| MTTFD | 291Â years |
Electronics
| Supply voltage | 10.8Â VÂ DCÂ ... 28.8Â VÂ DCÂ 1) |
|---|---|
| Ripple | â¤Â 5 Vpp 2) |
| Current consumption | <Â 100Â mAÂ 3) |
| Switching frequency | 50 kHz 4) 5) |
| Response time | 10 µs 6) 7) |
| Jitter | 5 µs 8) |
| Switching output | PNP, NPN |
| Switching output (voltage) | PNP: HIGH = VS - 3 V / LOW = 0 V, NPN: HIGH = VS / LOW ⤠3 V |
| Output current Imax. | 100Â mAÂ 9) |
| Retention time (ET) | 25Â ms, non-volatile memory |
| Time delay | None |
| Protection class | III |
| Circuit protection | UV connections, reverse polarity protectedOutput Q short-circuit protectedInterference pulse suppression |
Mechanics
| Housing material | VISTAL® |
|---|---|
| Optics material | COP |
| Connection type | Male connector M12, 4-pin |
| Weight | 94Â g |
Ambient data
| Ambient operating temperature | â20 °C ... +60 °C |
|---|---|
| Ambient temperature, storage | â25 °C ... +75 °C |
| Shock load | According to IECÂ 60068-2-27 (30Â g/11 ms) |
| Enclosure rating | IP67 |
| UL File No. | E181493 |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| ACMA declaration of conformity | â |
| Moroccan declaration of conformity | â |
| China RoHS | â |
| cULus certificate | â |
| Photobiological safety (IEC EN 62471) | â |
Classifications
| ECLASS 5.0 | 27270906 |
|---|---|
| ECLASS 5.1.4 | 27270906 |
| ECLASS 6.0 | 27270906 |
| ECLASS 6.2 | 27270906 |
| ECLASS 7.0 | 27270906 |
| ECLASS 8.0 | 27270906 |
| ECLASS 8.1 | 27270906 |
| ECLASS 9.0 | 27270906 |
| ECLASS 10.0 | 27270906 |
| ECLASS 11.0 | 27270906 |
| ECLASS 12.0 | 27270906 |
| ETIM 5.0 | EC001820 |
| ETIM 6.0 | EC001820 |
| ETIM 7.0 | EC001820 |
| ETIM 8.0 | EC001820 |
| UNSPSC 16.0901 | 39121528 |
