Sick IQC12-04BPPKQ8SA71
Inductive proximity sensors | IMC | IQC12-04BPPKQ8SA71 | Sensing range Sn: 0 mm … 4 mm | Installation type: Flush | Electrical wiring: DC 4-wire | Switching output: PNP | Output function: NC, NO | C…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Inductive proximity sensors | IMC | IQC12-04BPPKQ8SA71 | Sensing range Sn: 0 mm … 4 mm | Installation type: Flush | Electrical wiring: DC 4-wire | Switching output: PNP | Output function: NC, NO | Connection type: Cable with M12 male connector, 4-pin, 0.2 m | Smart Sensor: Enhanced Sensing, efficient communication, diagnosis, Smart Task (Counter + debouncing)
Specification
Features
| Housing | Rectangular |
|---|---|
| Dimensions (W x H x D) | 12 mm x 40 mm x 26 mm |
| Sensing range Sn | 0 mm ... 4 mm 1) |
| Safe sensing range Sa | 3.24Â mm |
| Number of switching points | Up to 4Â adjustable switching points or windows |
| Switching modes | Single point, Window mode, Two point mode, Visual adjustment indicator |
| Switching frequency Qint.1Â / Qint.2Â on Pin2 | 1,000Â Hz |
| Installation type | Flush |
| Connection type | Cable with M12 male connector, 4-pin, 0.2 m 2) |
| Switching output | PNP |
| Switching output detail | PNP |
| Output Q/C | Switching output or IO-Link mode |
| Output MFC | Switching output or input |
| Output function | NC / NO |
| Output characteristic | Programmable |
| Electrical wiring | DC 4-wire |
| Enclosure rating | IP68Â 3) |
| Special features | Smart Task, IO-Link |
| Pin 2Â configuration | External input, Teach-in, switching signal |
Mechanics/electronics
| Supply voltage | 10Â VÂ DCÂ ... 30Â VÂ DCÂ 1) |
|---|---|
| Ripple | â¤Â 10 % |
| Voltage drop | â¤Â 2 V 2) |
| Hysteresis | Programmable 3) |
| Reproducibility | â¤Â 5 % 4) 5) |
| Temperature drift (of Sr) | ± 10 % |
| EMC | According to ENÂ 60947-5-2 |
| Continuous current Ia | â¤Â 200 mA 6) |
| No load current | 35Â mA |
| Short-circuit protection | â |
| Power-up pulse protection | â |
| Shock and vibration resistance | 30 g, 11 ms / 10 ... 55 Hz, 1 mm |
| Ambient operating temperature | â25 °C ... +75 °C |
| Housing material | Plastic, VISTAL® |
| Sensing face material | Plastic, VISTAL® |
| Tightening torque, max. | <Â 1Â Nm |
| Teach-in accuracy | +/- 3% of Sr |
| Resolution, typical (range) | 20 μm (0 mm ... 4 mm) |
| Resolution, maximum (area) | 40 μm (0 mm ... 4 mm) |
Safety-related parameters
| MTTFD | 688Â years |
|---|---|
| DCavg | 0Â % |
| TM (mission time) | 20Â years |
Communication interface
| Communication interface | IO-Link V1.1 |
|---|---|
| Communication Interface detail | COM2 (38,4Â kBaud) |
| Cycle time | 5Â ms |
| Process data length | 32Â Bit |
| Process data structure | Bit 0Â = switching signal QL1Bit 1Â = switching signal QL2Bit 2Â = switching signal QInt3Bit 3Â = switching signal QInt4Bit 18Â ... 31Â = counting value |
| Factory setting | Switching Point 1: reference value 1Output: normally openPin 2Â configuration: input |
Reference values
| Note | Reference value in Digits for switching point in mm stored in the sensor |
|---|---|
| Reference value 1 | 4Â mm |
| Reference value 2 | 3Â mm |
| Reference value 3 | 2Â mm |
| Reference value 4 | 1Â mm |
Reduction factors
| Stainless steel (V2A, 304) | Approx. 0.7 |
|---|---|
| Aluminum (Al) | Approx. 0.4 |
| Copper (Cu) | Approx. 0.3 |
| Brass (Br) | Approx. 0.4 |
Installation note
| Remark | Associated graphic see "Installation" |
|---|---|
| A | 0Â mm |
| B | 12Â mm |
| C | 12Â mm |
| D | 12Â mm |
| E | 0Â mm |
| F | 32Â mm |
| G | 0Â mm |
Smart Task
| Smart Task name | Counter + debouncing |
|---|---|
| Logic function | WindowHysteresisDirect |
| Timer function | DeactivatedSwitch-on delayOff delayON and OFF delayImpulse (one shot) |
| Inverter | Adjustable |
| Maximum counting frequency | SIO Logic: 1000 Hz 1)IOL: 1000 Hz 2) |
| Counter reset | SIO Logic: 500 µsIOL: --- |
| Debounce time max. | SIO Logic: 30 s 1)IOL: 30 s 2) |
| Switching signal QL1 | Output type (dependant on the adjusted threshold) |
| Switching signal QL2 | Output type (dependant on the adjusted threshold) |
| Measuring value | Counting value |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| ACMA declaration of conformity | â |
| China RoHS | â |
| cULus certificate | â |
| IO-Link certificate | â |
| Information according to Art. 3 of Data Act (Regulation EU 2023/2854) | â |
Classifications
| ECLASS 5.0 | 27270101 |
|---|---|
| ECLASS 5.1.4 | 27270101 |
| ECLASS 6.0 | 27270101 |
| ECLASS 6.2 | 27270101 |
| ECLASS 7.0 | 27270101 |
| ECLASS 8.0 | 27270101 |
| ECLASS 8.1 | 27270101 |
| ECLASS 9.0 | 27270101 |
| ECLASS 10.0 | 27270101 |
| ECLASS 11.0 | 27270101 |
| ECLASS 12.0 | 27274001 |
| ETIM 5.0 | EC002714 |
| ETIM 6.0 | EC002714 |
| ETIM 7.0 | EC002714 |
| ETIM 8.0 | EC002714 |
| UNSPSC 16.0901 | 39122230 |
