Schneider Electric NSYSMX201040
Spacial SMX stainless steel 304L is a multi-purpose, floor-standing enclosure with a nominal height, width and depth of 2000mm, 1000mm and 400mm respectively This enclosure is designed to withstand ha…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Spacial SMX stainless steel 304L is a multi-purpose, floor-standing enclosure with a nominal height, width and depth of 2000mm, 1000mm and 400mm respectively This enclosure is designed to withstand harsh environments, with a IK10 (IEC62262) and an IP55 rating (IEC60529) for high protection against impacts, dust and water It is made with a Scotch-Brite® brushed surface finish and consists of a body, a cable gland plate, two plain doors, four mounting plate brackets, and a locking system with handle on the door The doors can be opened up to 120°, allowing easy access to the equipment inside The enclosure has a three-point lock with a handle with 5mm double-bar insert The doors and the mounting plate brackets can be removed for maintenance purposes The net weight of the enclosure is 126kg and it is certified by UL 508 and CAN/CSA 22 standards
Specification
| Range | PanelSeT |
|---|---|
| Product name | PanelSeT SMX |
| Enclosure type | Multi-purpose |
| Category | Compact enclosure |
| Nominal height | 2000 mm |
| Nominal width | 1000 mm |
| Nominal depth | 400 mm |
| Product installation | Floor-standing |
| Device composition | 1 body, 2 door, 1 cable gland plate, 1 locking system with handle: door, 4 mounting plate bracket |
| Body type | Single piece body folded and welded |
| Door type | Plain |
| Door opening side | Reversible (120 °) |
| Number of doors | Front face: 2 door(s) |
| Lock type | 3 points lock, handle with 5 mm double-bar insert |
| Type of gland plate | Plain |
| Accessibility for operation | Front |
| Mounting plate description | Without mounting plate |
| Material | Body and door: stainless steel 304L, Handle: zamak, Hinge: stainless steel |
| Removable parts | Door by hinges, Mounting plate bracket by screws, Cable gland plate by clips |
| Surface finish | Enclosure: Scotch-Brite® brushed, Handle: painted |
| Net weight | 126 kg |
| Standards | IEC 62208, UL, CUL |
| IP degree of protection | IP55 conforming to IEC 60529 |
| IK degree of protection | IK10 conforming to IEC 62262 |
| Product certifications | UL 508, CAN/CSA 22 |
| Environmental characteristic | Corrosive, Specific hygiene |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 213.000 cm |
| Package 1 Width | 105.000 cm |
| Package 1 Length | 49.000 cm |
| Package 1 Weight | 130.000 kg |
| Warranty | 18 months |
