Schneider Electric NSYSFX20860
SFX 304L stainless suitable enclosure, H2000xW800xD600mm, Scotch Brite® finish.
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Specification
| Range | PanelSeT |
|---|---|
| Product name | PanelSeT SFX |
| Enclosure type | Multi-purpose |
| Category | Suitable enclosure |
| Nominal height | 2000 mm |
| Nominal width | 800 mm |
| Nominal depth | 600 mm |
| Product installation | Floor-standing |
| Device composition | 1 structure, 1 locking system with handle: door, 4 mounting plate bracket, 1 cable gland plate, 1 door with reinforcement frame |
| Body type | Rear panel integrated, Single piece structure folded and welded |
| Door type | Plain |
| Number of doors | Front face: 1 door(s) |
| Door opening side | Reversible (120 °) |
| Lock type | 3 points lock, handle with 5 mm double-bar insert |
| Mounting plate description | Without mounting plate |
| Type of gland plate | Plain |
| Accessibility for operation | Front, Side |
| Removable parts | Door by hinges, Mounting plate bracket by screws, Cable gland plate by clips |
| Material | Structure and door: stainless steel 304L, Handle: zamak, Hinge: stainless steel |
| Surface finish | Enclosure: Scotch-Brite® brushed, Handle: painted |
| Net weight | 81 kg |
| Standards | IEC 62208, NEMA 4X |
| Product certifications | UL |
| IP degree of protection | IP66 conforming to IEC 60529 |
| IK degree of protection | IK10 conforming to IEC 62262 |
| Environmental characteristic | Specific hygiene, Corrosive |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 213.000 cm |
| Package 1 Width | 85.000 cm |
| Package 1 Length | 69.000 cm |
| Package 1 Weight | 98.000 kg |
| Warranty | 18 months |
