Schneider Electric NSYRCK38
Fixed racks allow mounting rackable electronic equipment with 19″ server racks in Spacial SF and Spacial SM enclosures The height is 1800mm The depth is 60mm Supports mounting of 38 units It is possib…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Fixed racks allow mounting rackable electronic equipment with 19″ server racks in Spacial SF and Spacial SM enclosures The height is 1800mm The depth is 60mm Supports mounting of 38 units It is possible to fasten 19″ fixed support bracket Depth adjustable in steps of 25mm The kit supplied with fixing elements and 2 uprights
Specification
| Range | PanelSeT |
|---|---|
| Accessory / separate part category | Mounting accessory |
| Product or component type | 19″ rack |
| Application | Electronic application |
| For enclosure nominal dimensions | – H: 1800 mm |
| Rack type | Fixed |
| Mounting location | On structure of enclosure |
| Mounting support | 19″ fixed support bracket |
| Range compatibility | PanelSeT PanelSeT SF, PanelSeT PanelSeT SM |
| Device composition | Fixing elements, 2 upright |
| Quantity per set | Set of 1 |
| Number of units 19" | 38 |
| Rack coverage | Complete |
| Material | Steel |
| Enclosure/cubicle description | Floor-standing enclosure |
| Surface finish | Zinc coated |
| Fixing mode | By fixing element |
| Adjustment | Adjustable in depth every 25 mm |
| Permanent permissible load | 400 kg |
| Height | 1800 mm |
| Width | Nominal: 600 mm, Nominal: 800 mm |
| Depth | 60 mm |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 6.000 cm |
| Package 1 Width | 12.000 cm |
| Package 1 Length | 172.000 cm |
| Package 1 Weight | 4.996 kg |
| Unit Type of Package 2 | P2M |
| Number of Units in Package 2 | 40 |
| Package 2 Height | 34.000 cm |
| Package 2 Width | 120.000 cm |
| Package 2 Length | 200.000 cm |
| Package 2 Weight | 231.000 kg |
| Warranty | 18 months |
