Schneider Electric NSYPMM75
Thalassa PLA/PHD metallic mounting plate. For enclosure H is500 x W is750 mm. Step slides mounting location or on back inserts location (fixing by screw type M8). Plain mounting plate. 150 Kg permanen…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Thalassa PLA/PHD metallic mounting plate. For enclosure H is500 x W is750 mm. Step slides mounting location or on back inserts location (fixing by screw type M8). Plain mounting plate. 150 Kg permanent permissible load. Galvanised Steel. Grey RAL 7035. Can be installed in enclosure with inverted dimensions.
Specification
| Range |
PanelSeT |
|---|---|
| Accessory / separate part category |
Mounting accessory |
| Product or component type |
Mounting plate |
| Device application |
Multi-purpose |
| Enclosure nominal dimensions |
– |
| Mounting location |
Back inserts, Step slide |
| Mounting plate description |
Plain |
| Range compatibility |
PanelSeT PLA, PanelSeT PHD |
| Device composition |
1 mounting plate |
| Material |
Galvanised steel |
| Fixing mode |
By screws – screw type M8 – on back inserts location |
| Permanent permissible load |
150 kg |
| Height |
Nominal: 750 mm, Real: 640 mm |
| Width |
Nominal: 500 mm, Real: 375 mm |
| Depth |
Real : 125 mm |
| Thickness |
2.5 mm |
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
0.300 cm |
| Package 1 Width |
37.500 cm |
| Package 1 Length |
64.000 cm |
| Package 1 Weight |
4.600 kg |
| Unit Type of Package 2 |
PAM |
| Number of Units in Package 2 |
34 |
| Package 2 Height |
30.000 cm |
| Package 2 Width |
100.000 cm |
| Package 2 Length |
120.000 cm |
| Package 2 Weight |
171.400 kg |
| Warranty |
18 months |
