Schneider Electric NSYPLAZ773G
This PLAZ version of the PLA is a versatile, floor-standing enclosure that is suitable for various applications It measures 750mm in height, 750mm in width, and 320mm in depth It is made of polyester…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
This PLAZ version of the PLA is a versatile, floor-standing enclosure that is suitable for various applications It measures 750mm in height, 750mm in width, and 320mm in depth It is made of polyester reinforced with fiberglass, providing durability and resistance to harsh environments, including outdoor and industrial settings The enclosure is available in grey (RAL 7035) and consists of two side parts, one plain front door, one rear panel, and one plinth The door can be opened up to 120° from either the right or left side, and is secured with a two-point handle lock and a 5mm double-bar insert The door and rear panel are removable for easy maintenance
Specification
| Range |
PanelSeT |
|---|---|
| Product name |
PanelSeT PLA |
| Enclosure type |
Multi-purpose |
| Product or component type |
Suitable enclosure |
| Version |
PLAZ |
| Nominal height |
750 mm |
| Nominal width |
750 mm |
| Nominal depth |
320 mm |
| Enclosure mounting |
Floor-standing |
| Device composition |
1 top part, 1 bottom part, 2 side part, 1 rear panel, 1 door, 1 plinth |
| Body type |
Sealed top and open bottom part assembled with side parts |
| Door type |
Plain front |
| Number of doors |
1 door(s) |
| Door opening side |
Reversible (120 °) |
| Lock type |
2 points handle lock, 5 mm double-bar |
| Accessibility for operation |
Bottom, Front, Rear |
| Removable parts |
Door by hinges, Rear panel by fixing element |
| Material |
Polyester reinforced with fibreglass |
| Colour |
Grey (RAL 7035) |
| Standards |
IEC 62208 |
| Product certifications |
Veritas |
| Electrical insulation class |
Class II |
| IP degree of protection |
IP54 conforming to IEC 60529 (plinth type open bottom) |
| IK degree of protection |
IK10 conforming to IEC 62262 (plain door) |
| Fire resistance |
960 °C conforming to IEC 62208 |
| Ambient air temperature for storage |
-35…90 °C |
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
38.500 cm |
| Package 1 Width |
78.500 cm |
| Package 1 Length |
81.000 cm |
| Package 1 Weight |
23.000 kg |
| Unit Type of Package 2 |
PAM |
| Number of Units in Package 2 |
6 |
| Package 2 Height |
175.000 cm |
| Package 2 Width |
100.000 cm |
| Package 2 Length |
120.000 cm |
| Package 2 Weight |
151.000 kg |
| Warranty |
18 months |
