Schneider Electric NSYMR33
Monobloc perforated mounting plates with universal perforations for Spatial CRN, S3D, S3X and Thalassa PLM. The dimensions are (H) 300 mm x (W) 300 mm. The mounting plate can be fixed using step slide…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Monobloc perforated mounting plates with universal perforations for Spatial CRN, S3D, S3X and Thalassa PLM. The dimensions are (H) 300 mm x (W) 300 mm. The mounting plate can be fixed using step slide or by direct fixing on backstuds (M8 screws). It is Telequick perforated. The dimensions of the cut-out are 11 mm x 26 mm. It count a total of 144 slots. The product is made of steel with zinc coated surface finish. It can be installed in the rear of the enclosure. This product is qualified as a green premium, with minimal use of hazardous substances.
Specification
| Range |
PanelSeT |
|---|---|
| Accessory / separate part category |
Mounting accessory |
| Product or component type |
Mounting plate |
| Device application |
Multi-purpose |
| Enclosure nominal dimensions |
– H: 300 mm W: 300 mm |
| Mounting location |
Step slide, Direct fixing on backstuds |
| Mounting plate description |
Telequick perforated |
| Range compatibility |
PanelSeT S3D, PanelSeT CRN, PanelSeT PLM |
| Quantity per set |
Set of 1 |
| Material |
Steel |
| Surface finish |
Zinc coated |
| Fixing mode |
Screwed on backstuds – screw type M8, By fixing element |
| Height |
255 mm |
| Width |
251 mm |
| Depth |
15 mm |
| Thickness |
2 mm |
| Net weight |
0.506 kg |
| Number of slots |
144 |
| Variant particularity |
Installation in rear of enclosure |
| Cut-out dimensions |
11 x 26 mm |
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
1.700 cm |
| Package 1 Width |
25.100 cm |
| Package 1 Length |
25.500 cm |
| Package 1 Weight |
512.000 g |
| Unit Type of Package 2 |
PAM |
| Number of Units in Package 2 |
276 |
| Package 2 Height |
50.000 cm |
| Package 2 Width |
100.000 cm |
| Package 2 Length |
120.000 cm |
| Package 2 Weight |
161.000 kg |
| Warranty |
18 months |
