Schneider Electric MCSESP083F23G0T

This product is part of the Modicon Networking range, an offer of Modicon PoE Managed Switch. This managed switch comes with Ethernet TCP/IP protocol. It comes with 8 copper cable transmission ports. It can operate between -40 to 70 degree celcius. Power over Ethernet feature is available on this switch. It provides simple and complex connectivity for multiple Ethernet device, network management, enhanced cyber security and more advanced switching features. This product works at a power consumption of 106W and a rated voltage of 24V DC. It has a removable 6-pin power supply connector. Its dimensions are 125mm (width) x 138mm (height) x 111mm (depth) and weighs 1.40 kg. It allows supplying current to a powered device, such as an IP camera, via the 4 twisted pair cable, which at the same time are used as Ethernet communiction. It is CE, UL, RCM, EAC, UKCA, DNV certified and conforms to UL 61010, EN/IEC 61131 and EN/IEC 62368-1 standards. It is designed to be mounted on a 35mm symmetrical DIN rail. It provides low power consumption and compact footprint. It also provides simple connectivity for multiple Ethernet device. The Modicon Networking range offers you a smart and flexible way to integrate Ethernet solutions into your operation, from the device level to the control network and to your corporate network.
