Schneider Electric CCTDD20004
STD – SAE – remote control dimmer – 1000 W
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Specification
| Range of product |
Acti9 |
|---|---|
| Product name |
Acti9 STD |
| Product or component type |
Remote control dimmer |
| Device short name |
STD |
| Device application |
Building |
| Load type |
230 V AC halogen lamp: 60…1000 W, 230 V AC incandescent lamp: 60…1000 W, low voltage halogen lamp with conventional transformer: 60…1000 W, motor: 60…600 W |
| Control type |
Local control: push-button, Remote control: push-button |
| Power consumption in VA |
0.8 VA |
| Thermal losses |
3 W |
| Input type |
Push-button 4 allows control up to 20 dimmers |
| [Ue] rated operational voltage |
230 V AC +/- 10 % at 50 Hz |
| Input voltage |
12…30 V AC/DC |
| Protection type |
Electronic over temperature protection, Single shot thermal fuse, Electronic overvoltage protection, Electronic overload protection |
| Mounting support |
DIN rail |
| 9 mm pitches |
8 |
| Connected auxiliaries |
Maximum 25 auxiliary push-buttons without light indication, distance : < 50 m, Maximum 5 auxiliary push-buttons with light indication, distance : < 50 m |
| Connections - terminals |
Screw terminals, 2 cable(s) 4 mm² top, Screw terminals, 5 cable(s) 2.5 mm² bottom |
| Maximum cable distance between devices |
50 m |
| Height |
85 mm |
| Width |
72 mm |
| Depth |
62 mm |
| Net weight |
130 g |
| IP degree of protection |
IP20 |
| Standards |
EN 60669-2-1 |
| Directives |
73/23/EEC – low voltage directive, 89/336/EEC – electromagnetic compatibility |
| Ambient air temperature for operation |
0…70 °C |
| Ambient air temperature for storage |
0…60 °C |
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
8.100 cm |
| Package 1 Width |
9.700 cm |
| Package 1 Length |
9.700 cm |
| Package 1 Weight |
198.000 g |
| Unit Type of Package 2 |
CAR |
| Number of Units in Package 2 |
24 |
| Package 2 Height |
20.600 cm |
| Package 2 Width |
30.500 cm |
| Package 2 Length |
40.900 cm |
| Package 2 Weight |
5.074 kg |
| Warranty |
18 months |
