Pepperl Fuchs VBA-4E4E-G11-ZAJ-F

AS-Interface sensor module. G11 module, 2 x 4 inputs. Node type: A/B node. AS-Interface specification: V3.0. Required gateway specification: ≥ V2.1. Profile: S-0.A.2. IO code0ID codeAID1 codeNode 1: 1Node 2: 2ID2 code2: . IO code: 0. ID code: A. ID1 code: Node 1: 1Node 2: 2. ID2 code: 2. UL File Number: E223772. LED AS-i/FAULT: 2 Dual LEDs green/redgreen: AS-Interface voltagered: Communication erroryellow/red flashing: Address 0green/red flashing: Sensor supply overload. LED IN: switching state (input); 8 LED yellow. Rated operating voltage: 18,0 … 31.6 V from AS-Interface. Rated operating current: ≤ 80 mA (without sensors) / max. 280 mA. Protection class: III. Surge protection: Ue: Over voltage category III, safe isolated power supplies (PELV). Number/Type: 2x 4 inputs for 2- or 3-wire sensors (PNP), DC alternative 2x 2 inputs for 4-wire sensors (PNP), DC. Supply: from AS-Interface. Voltage: 12 … 31 V. Current loading capacity: ≤ 200 mA, overload and short-circuit protected. Input current: ≤ 9 mA (limited internally). Switching point: according to DIN EN 61131-2 (Type 2). 0 (unattenuated)≤ 3 mA1 (attenuated)≥ 5 mA: . 0 (unattenuated): ≤ 3 mA. 1 (attenuated): ≥ 5 mA. Signal delay: < 1 ms (input/AS-Interface). Electromagnetic compatibility: . Directive 2014/30/EUEN 62026-2:2013 EN 61000-6-2:2005, EN 61000-6-4:2007: . Directive 2014/30/EU: EN 62026-2:2013 EN 61000-6-2:2005, EN 61000-6-4:2007. Degree of protection: EN 60529:2000. Fieldbus standard: EN 62026-2:2013. Input: EN 61131-2:2007. Emitted interference: EN 61000-6-4:2007. AS-Interface: EN 62026-2:2013. Noise immunity: EN 61000-6-2:2005, EN 61326-1:2006, EN 62026-2:2013. Ambient temperature: -25 … 70 °C (-13 … 158 °F). Storage temperature: -25 … 85 °C (-13 … 185 °F). Relative humidity: 85 % , noncondensing. Climatic conditions: For indoor use only. Altitude: ≤ 2000 m above MSL. Shock and impact resistance: 30 g, 6 ms in 6 spatial directions, 3 shocks 10 g, 16 ms in 6 spatial directions, 1000 shocks. Vibration resistance: 0.35 mm 10 … 57 Hz , 5 g 57 … 2000 Hz, 10 cycles. Pollution degree: 3. Degree of protection: IP68 / IP69K. Connection: AS-Interface: AS-Interface flat cable Inputs: M12 round connector. Material: . HousingPBT PCMounting screwStainless steel 1.4305 / AISI 303: . Housing: PBT PC. Mounting screw: Stainless steel 1.4305 / AISI 303. Mass: 200 g. Tightening torque, housing screws: 1.8 Nm. Tightening torque, cable gland: 0.4 Nm. Dimensions: . Height35 mmDiameter85 mm: . Height: 35 mm. Diameter: 85 mm. Mounting: Mounting plate
