Pepperl Fuchs RL39-54/32/40a/73c/82a-Y302645

Retroreflective sensor. Retroreflective sensor for standard applications, polarization filter, detection range 12 m, red light, sensitivity adjuster, light/dark on, prefault output, PNP output, M12 plug, Glare protected with polarization filter, Visible red light, Light-on/dark-on, switchable, Degree of protection IP54. Effective detection range: 0 … 5 m. Reflector distance: 0.1 … 5 m. Threshold detection range: 6 m. Reference target: H50 reflector. Light source: LED red. Light type: modulated visible red light. Polarization filter: yes. Ambient light limit: IEC / EN 60947-5-2 , 10000 Lux. MTTFd: 800 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Function indicator: LED yellow: switching stateLED red: pre-fault indication. Control elements: Sensing range adjuster, light-on/dark-on changeover switch. Operating voltage: 10 … 30 V DC. Ripple: 10 %. No-load supply current: ≤ 20 mA. Time delay before availability: ≤ 300 ms. Stability alarm output: 1 PNP, active when falling short of operating reserve. Switching type: light/dark on. Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector. Switching voltage: max. 30 V DC. Switching current: max. 200 mA , resistive load. Voltage drop: ≤ 3 V. Switching frequency: ≤ 300 Hz. Response time: ≤ 1.5 ms. Product standard: EN 60947-5-2. Approvals: CE. Ambient temperature: -25 … 55 °C (-13 … 131 °F). Storage temperature: -40 … 70 °C (-40 … 158 °F). Degree of protection: IP54. Connection: 4-pin, M12 x 1 connector. Material: . HousingPBTOptical facePMMA: . Housing: PBT. Optical face: PMMA. Mass: approx. 100 g. Dimensions: . Height64 mmWidth25 mmDepth75 mm: . Height: 64 mm. Width: 25 mm. Depth: 75 mm. Scope of delivery: Reflector
