Pepperl Fuchs NBB2-V3-Z4L

Inductive sensor. Switching function: Normally open (NO), Output type: Two-wire with minimum off-state current, Installation: flush, Output polarity: DC, Output type: 2-wire, Construction type: Rectangular, Series: Rectangular type, Operating voltage: 3.7 … 30 V DC, Type of voltage: DC, Connection type: cable, Housing material: PBT, Degree of protection: IP67, Material: PVC. Switching function: Normally open (NO). Output type: Two-wire with minimum off-state current. Rated operating distance: 2 mm. Installation: flush. Output polarity: DC. Assured operating distance: 0 … 1.62 mm. Actual operating distance: 1.8 … 2.2 mm typ.. Reduction factor rAl: 0.25. Reduction factor rCu: 0.2. Reduction factor r304: 0.7. Output type: 2-wire. Operating voltage: 3.7 … 30 V DC. Switching frequency: 0 … 700 Hz. Hysteresis: 1 … 10 % typ. 5 %. Reverse polarity protection: reverse polarity protected. Short-circuit protection: pulsing. Voltage drop: ≤ 3.7 V. Operating current: 2 … 30 mA. Lowest operating current: 2 mA. Off-state current: ≤ 190 µA. Switching state indicator: LED, yellow. Tightening torque, fastening screws: 0.4 Nm. MTTFd: 1880 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Standard conformity: . StandardsEN IEC 60947-5-2: . Standards: EN IEC 60947-5-2. UL approval: cULus Listed, General Purpose, Class 2 Power Source. Ambient temperature: -25 … 70 °C (-13 … 158 °F). Storage temperature: -40 … 85 °C (-40 … 185 °F). Connection type: cable. Housing material: PBT. Sensing face: PBT. Degree of protection: IP67. Cable: . Wire end ferrulesyesCable diameter3 mm ± 0.2 mmBending radius> 10 x cable diameterMaterialPVCColorgreyNumber of cores2Core cross section0.14 mm2LengthL130 mm: . Wire end ferrules: yes. Cable diameter: 3 mm ± 0.2 mm. Bending radius: > 10 x cable diameter. Material: PVC. Color: grey. Number of cores: 2. Core cross section: 0.14 mm2. Length: 130 mm. Dimensions: . Height10.2 mmWidth27.8 mmLength16 mm: . Height: 10.2 mm. Width: 27.8 mm. Length: 16 mm
