Omron S8VS-18024A
Power supply, 180W, 100-240 VAC input, 24 VDC 7.5A output, DIN rail mounting, digital display with running voltage and current, peak current, and maintenance monitor function with settable alarm point
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Power supply, 180W, 100-240 VAC input, 24 VDC 7.5A output, DIN rail mounting, digital display with running voltage and current, peak current, and maintenance monitor function with settable alarm point
Specification
| Type |
DIN-rail |
|---|---|
| Mounting method |
DIN rail |
| Phase |
Single |
| Output voltage |
24 V |
| Power output |
180 W |
| Efficiency |
87 % |
| Rated output current |
7.5 A |
| Temperature range |
25-85 °C |
| Terminal type |
Screw |
| Communication port(s) |
None |
| Alarm function |
Transistor – sinking |
| Number of output branches |
1 |
| Rated supply voltage at AC 50 Hz |
100-240 V |
| Allowable supply voltage AC |
85-264 V |
| Allowable supply voltage DC |
80-370 V |
| Product Width (unpacked) |
75 mm |
| Product Height (unpacked) |
115 mm |
| Product Depth (unpacked) |
125.3 mm |
