Omron G3PJ-515B-PU DC12-24
Solid-state relay, 1 phase, 23A, 100-480V AC, with heat sink, DIN rail mount, input voltage 12-24V DC with Push-in terminals
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Solid-state relay, 1 phase, 23A, 100-480V AC, with heat sink, DIN rail mount, input voltage 12-24V DC with Push-in terminals
Specification
| Application | Power control |
|---|---|
| Number of phases | 1 |
| Number of poles | 1 |
| Mounting method | DIN rail/screw |
| Terminal type | Push-in, Screw |
| Complete with socket | No |
| LED indicator | Yes |
| Rated operational voltage, AC | 100-480 V |
| Operating voltage range, AC | 75-528 V |
| Rated operation current Ie at AC-1 | 23 A |
| Rated load current Close mounting | 15 A |
| Permissible I²t value | 1350 A²s |
| Product Height (unpacked) | 100 mm |
| Product Width (unpacked) | 22.5 mm |
| Product Depth (unpacked) | 100 mm |
| Supply voltage DC | 12-24 V |
| Control current max. | 7 mA |
| Must operate voltage max. | 9.6 V |
| Must release voltage min. | 1 V |
| Maximum operating temperature | 80 °C |
| Minimum operating temperature | -30 °C |
| Isolation | Phototriac |
| Switching at zero-crossing | Yes |
