Omron D4NS-9EF
Safety interlock switch, 1 NC/1 NO, 10 A, M12 connector
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Safety interlock switch, 1 NC/1 NO, 10 A, M12 connector
Specification
| Door switch type | Key-operated |
|---|---|
| Guard-lock | No |
| Material housing | Resin |
| Material head | Resin |
| Ambient temperature (operating) | -30-70 °C |
| Direction of operation | Adjustable |
| Door contacts NC | 1 |
| Door contacts NO | 1 |
| Switch action | Slow action |
| Make before break | Yes |
| LED indicator | No |
| Connection method | Connector M12 |
| Cable length | 0 m |
| Degree of protection (IP) | IP67 |
| Conduit size | Not Applicable |
| Number of conduits | |
| Shape | Cuboid |
| Overall length of sensor | 110 mm |
| Height of sensor | 30 mm |
| Width of sensor | 31 mm |
| Switch without actuator | Yes |
