Omron CP2E-S40DT1-D
CP2E series compact PLC – Standard Type; 24 DI, 16 DO; PNP output; Power supply 24 VDC; 8 kStep Program memory
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
CP2E series compact PLC – Standard Type; 24 DI, 16 DO; PNP output; Power supply 24 VDC; 8 kStep Program memory
Specification
| Supply voltage type |
DC |
|---|---|
| Input type |
PNP/NPN |
| Number of digital inputs |
24 |
| Output type |
PNP |
| Number of digital outputs |
16 |
| Program capacity |
16 K steps |
| Data memory capacity |
8 K words |
| Logic execution time |
0.23 µs |
| Communication port(s) |
Serial RS-232C, Serial RS-485, USB |
| Number of Ethernet ports |
0 |
| Number of USB ports |
1 |
| Number of RS-232 ports |
1 |
| Number of RS-485 ports |
1 |
| Number of encoder input channels |
6 |
| Max. encoder input frequency |
100 kHz |
| Max. number of PTP axes |
2 |
| Max. pulse output frequency |
100 kHz |
| Function Block programming |
Yes |
| Battery-free memory backup |
Yes |
| Real-time clock |
Yes |
| Analogue option boards |
No |
| Max. number of analogue I/O channels |
24 |
| Max. number of local I/O points |
160 |
| Max. number of expansion units |
3 |
| Built-in auxiliary 24 VDC output |
0 mA |
| Operating temperature range |
-20-60 °C |
| Product Height (unpacked) |
90 mm |
| Product Width (unpacked) |
150 mm |
| Product Depth (unpacked) |
80 mm |
| Product Weight (unpacked) |
605 g |
