IFM ZJF097
ZJF097
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
ideal hardware for analysis and DataScience applications with production-related software
Specification
Application
| Application | IT hardware to operate production-related software providing memory capacity and processing power Easy set-up without requiring special IT knowledge |
|---|---|
| Compatibility | can be used independent of IT infrastructure can be integrated in IT network structure at any time |
| Connectivity | interfaces for sensor and IT network |
Electrical data
| Operating voltage[V] [V] | 10...36 DC |
|---|---|
| Power consumption[W] [W] | 21; (maximum: 47) |
Outputs
| Number of video outputs | 2; (DisplayPort) |
|---|
Software / programming
| Note on licence | hardware bound; software must be ordered and installed separately for operation |
|---|
Interfaces
| Communication interface | Ethernet; RS232; USB |
|---|---|
| Number of Ethernet interfaces | 3; (GBit) |
| Number of R232 interfaces | 4; (RS232/RS422/RS485) |
| Number of USB interfaces | 4; (3 x USB 3.2 Gen1; 1 x USB 2.0 Type A) |
Operating conditions
| Ambient temperature[°C] [°C] | 0...70 |
|---|---|
| Storage temperature[°C] [°C] | -20...60 |
| Max. relative air humidity[%] [%] | 95; (40 °C non condensing) |
| Protection | IP 40 |
Tests / approvals
| Shock resistance | IEC60068-2-27 50 g 11 ms |
|---|---|
| IEC60068-2-27 | 50 g 11 ms |
| Vibration resistance | IEC 60068-2-64 4 Grms / 5...500 Hz |
| IEC 60068-2-64 | 4 Grms / 5...500 Hz |
Mechanical data
| Weight[g] [g] | 2185.1 |
|---|---|
| Dimensions[mm] [mm] | 45 x 140 x 200 |
Hardware
| Processor | Intel Core i5-1145G7E quad-core |
|---|---|
| TPM chip | V 2.0 |
| BIOS | AMI UEFI (256 Mbit) |
| RAM | 16 GB |
| Mass storage | 1 TB SSD |
Accessories
| Items supplied | Power supply: 1, 24 V DC |
|---|
Remarks
| Notes | the required licences to operate software products must be ordered separately |
|---|---|
| Pack quantity | 1 pcs. |
