IFM VSA201
VSA201
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
For the reliable vibration detection of machines and equipment
For connection to a diagnostic electronics for vibration sensors
Large operating temperature range and high protection rating for the requirements of harsh industrial environments
Compact and robust stainless steel housing with high mechanical overload protection
Very good repeatability and low linearity deviation
Specification
Product characteristics
| Measuring range of vibration[g] [g] | -250...250 |
|---|---|
| Frequency range[Hz] [Hz] | 1...6000 |
| Measuring principle | capacitive |
Application
| Design | for connection to external diagnostic electronics VSE |
|---|---|
| Application | vibration detection |
Electrical data
| Operating voltage[V] [V] | 7.2...10.8 DC |
|---|---|
| Current consumption[mA] [mA] | < 15 |
| Min. insulation resistance[MΩ] [MΩ] | 100; (500 V DC) |
| Protection class | III |
| Reverse polarity protection | yes |
| Sensor type | microelectromechanical system (MEMS) |
Outputs
| Analogue current output[mA] [mA] | 0...10 |
|---|---|
| Max. load[Ω] [Ω] | 300 |
Measuring/setting range
| Measuring range of vibration[g] [g] | -250...250 |
|---|---|
| Frequency range[Hz] [Hz] | 1...6000 |
| Measuring principle | capacitive |
| Sensitivity[µA/g] [µA/g] | 14.2 |
| Number of measurement axes | 1 |
Accuracy / deviations
| Linearity deviation | 5 % |
|---|
Operating conditions
| Ambient temperature[°C] [°C] | -30...125 |
|---|---|
| Note on ambient temperature | UL application: < 70 °C |
| Storage temperature[°C] [°C] | -30...125 |
| Protection | IP 67; IP 68; IP 69K |
Tests / approvals
| EMC | EN 61000-6-2 EN 61000-6-3 |
|---|---|
| Shock resistance | DIN EN 60068-2-27 50 g 11 ms 500 g 1 ms |
| DIN EN 60068-2-27 | 50 g 11 ms |
| Vibration resistance | DIN EN 60068-2-6 20 g / 10 ... 2000 Hz |
| DIN EN 60068-2-6 | 20 g / 10 ... 2000 Hz |
| MTTF[years] [years] | 3094 |
Mechanical data
| Weight[g] [g] | 49 |
|---|---|
| Housing | cylindrical |
| Type of mounting | M8 x 1,25 |
| Dimensions[mm] [mm] | Ø 17 / L = 53 |
| Materials | housing: stainless steel (316L/1.4404) |
| Tightening torque[Nm] [Nm] | 8 |
Accessories
| Items supplied | washer, conical |
|---|
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| Connector | 1 x M12; coding: A; Maximum cable length: 250 m |
|---|
