IFM SD6100

SD6100

Request for Quote

Add to compare
Add to wishlist

Shipping & Delivery

  • Courier delivery

Our courier will deliver to the specified address

5-6 Days

From €20

  • DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

From €40

  • Warranty 1 year

More details

  • Free 30-Day returns

More details

Description

Precise measurement of flow, consumption and medium temperature
High accuracy, repeatability and measurement dynamics
For detecting argon (Ar), carbon dioxide (CO2), nitrogen (N2)
With switching output, analogue output and pulse output
Clearly visible 4-digit LED display
Convenient operation via buttons or parameter setting via IO-Link

Specification

Product characteristics

Number of inputs and outputsNumber of digital outputs: 2; Number of analogue outputs: 1
Process connectionthreaded connection R 1/2 external thread DN15
Measuring range[m³/h] [m³/h]0.2...75

Application

Applicationfor industrial applications
MediaArgon (Ar); carbon dioxide (CO2); nitrogen (N2)
Medium temperature[°C] [°C]0...60
Pressure rating16 bar
1.6 MPa
16 bar1.6 MPa

Electrical data

Operating voltage[V] [V]18...30 DC; (to SELV/PELV)
Current consumption[mA] [mA]< 100
Protection classIII
Reverse polarity protectionyes
Power-on delay time[s] [s]1

Inputs / outputs

Number of inputs and outputsNumber of digital outputs: 2; Number of analogue outputs: 1

Outputs

Total number of outputs2
Output signalswitching signal; analogue signal; pulse signal; IO-Link; (configurable)
Electrical designPNP
Number of digital outputs2
Output functionnormally open / normally closed; (parameterisable)
Max. voltage drop switching output DC[V] [V]2
Permanent current rating of switching output DC[mA] [mA]250; (per output)
Number of analogue outputs1
Analogue current output[mA] [mA]4...20; (scalable)
Max. load[Ω] [Ω]500
Pulse outputconsumed quantity meter
Short-circuit protectionyes
Type of short-circuit protectionpulsed
Overload protectionyes

Measuring/setting range

Low flow cut-off LFC[m³/h] [m³/h]< 1.3
Measuring dynamics1:300
Measuring range[m³/h] [m³/h]0.2...75
Display range[m³/h] [m³/h]0...90
Resolution[m³/h] [m³/h]0.1
Set point SP[m³/h] [m³/h]0.7...75
Reset point rP[m³/h] [m³/h]0.4...74.7
Analogue start point ASP[m³/h] [m³/h]0...60
Analogue end point AEP[m³/h] [m³/h]15...75
In steps of[m³/h] [m³/h]0.1
Pulse value0.001...1 000 000 m³
In steps of0.001...1000 m³
Pulse length[s] [s]0,012...2
Measuring range[°C] [°C]0...60
Display range[°C] [°C]-12...72
Resolution[°C] [°C]0.2
Set point SP[°C] [°C]0.4...60
Reset point rP[°C] [°C]0...59.8
Analogue start point[°C] [°C]0...48
Analogue end point[°C] [°C]12...60
In steps of[°C] [°C]0.2

Accuracy / deviations

Repeatability[% of the measured value] [% of the measured value]± 1,5
Accuracy (in the measuring range)± (6 % MW + 0,6 % MEW); (conditions: installation to DIN ISO 2533; installation in pipes: DN15)
Accuracy[K] [K]± 2; (medium flow in the limit area of the flow measurement range)

Response times

Response time[s] [s]0.1; (dAP = 0)
Damping process value dAP in steps[s] [s]0 - 0,2 - 0,4 - 0,6 - 0,8 - 1

Software / programming

Parameter setting optionsFlow monitoring; quantity meter; Preset counter; hysteresis / window; normally open / normally closed; current/pulse output; display can be rotated and switched off; Display unit; medium selection

Interfaces

Communication interfaceIO-Link
Transmission typeCOM2 (38,4 kBaud)
IO-Link revision1.1
SDCI standardIEC 61131-9
ProfilesSmart Sensor - SSP 0
Generic Profiled Sensor
Function
Device identification
Function
Process data variable
Function
Device diagnosis
Smart Sensor - SSP 0Generic Profiled Sensor
FunctionDevice diagnosis
SIO modeyes
Required master port typeA
Process data analogue3
Process data binary2
Min. process cycle time[ms] [ms]4.1
Supported DeviceIDsdefault
265
default265

Operating conditions

Ambient temperature[°C] [°C]0...60
Storage temperature[°C] [°C]-20...85
Max. relative air humidity[%] [%]90
ProtectionIP 65

Tests / approvals

EMCEN 61000-4-2 ESD
4 kV CD / 8 kV AD
EN 61000-4-3 HF radiated
10 V/m
EN 61000-4-4 Burst
2 kV
EN 61000-4-6 HF conducted
10 V
EN 61000-4-2 ESD4 kV CD / 8 kV AD
EN 61000-4-3 HF radiated10 V/m
EN 61000-4-4 Burst2 kV
EN 61000-4-6 HF conducted10 V
CPA approvalmodel number
003TG
accuracy class
-
maximum allowable error
± 7 % FS
Q (min)
0,2 m³/h (N2)
0,2 m³/h (CO2)
0,4 m³/h (Ar)
Q (t)
-
Q (max)
75 m³/h (N2)
74,7 m³/h (CO2)
122 m³/h (Ar)
model number003TG
accuracy class-
maximum allowable error± 7 % FS
Q (min)0,2 m³/h (N2)
Q (t)-
Q (max)75 m³/h (N2)
Vibration resistanceDIN IEC 68-2-6
5 g (55...2000 Hz)
DIN IEC 68-2-65 g (55...2000 Hz)
MTTF[years] [years]227
Pressure Equipment DirectiveSound engineering practice; can be used for group 2 fluids; group 1 fluids on request

Mechanical data

Weight[g] [g]963.5
Dimensions[mm] [mm]300 x 45 x 80.4
MaterialsPBT-GF20; PC; PC; stainless steel (304/1.4301); FKM
Materials (wetted parts)stainless steel (304/1.4301); ceramics glass passivated; PEEK; polyester; FKM; aluminium anodised
Tightening torque[Nm] [Nm]50
Process connectionthreaded connection R 1/2 external thread DN15

Displays / operating elements

DisplayDisplay unit
4 x LED, green (Nl/min, Nm³/h, Nm³, °C)
function display
1 x LED, yellow
switching status
2 x LED, yellow
measured values
alphanumeric display, 4-digit
programming
alphanumeric display, 4-digit
Display unitNl/min; Nm³/h; Nm³; °C
function display1 x LED, yellow
switching status2 x LED, yellow
measured valuesalphanumeric display, 4-digit
programmingalphanumeric display, 4-digit

Remarks

RemarksMW = measured value
MEW = Final value of the measuring range
Measuring, display and setting ranges refer to the standard volume flow according to DIN ISO 2533.
Pack quantity1 pcs.

Electrical connection

Connector1 x M12; coding: A
