IFM O2D920
O2D920
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Dark field illumination for accentuating surface characteristics such as needled codes, scratches or nicks
Permanent light or pulse operation
With visible red light
Compact and robust housing
Specification
Product characteristics
| Type of light | red light |
|---|
Application
| Illuminated field[mm] [mm] | Ø 90 |
|---|---|
| Design | dark field |
| Type of operation | pulsed or permanent operation |
Electrical data
| Operating voltage[V] [V] | 24 DC |
|---|---|
| Current consumption[mA] [mA] | 400 |
| Type of light | red light |
| Wave length[nm] [nm] | 617 |
Inputs
| Trigger | 24 V PNP |
|---|
Operating conditions
| Ambient temperature[°C] [°C] | -10...55 |
|---|---|
| Storage temperature[°C] [°C] | -25...75 |
| Protection | IP 54 |
| Overheat protection | yes; (deactivation at 65...75 °C) |
Tests / approvals
| Photobiological safety | exempt group; (DIN EN 62471:2008) |
|---|
Mechanical data
| Weight[g] [g] | 369 |
|---|---|
| Dimensions[mm] [mm] | 155 x 130 x 9.8 |
| Materials | aluminium black anodised |
| Lens material | glass |
Displays / operating elements
| Display | combined LED, three-colour illumination status yellow operation green excess temperature red |
|---|---|
| illumination status | yellow |
| operation | green |
| excess temperature | red |
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| Cable | 0.3 m, PUR, black; 4 x 0.34 mm² |
|---|---|
| Connector | 1 x M12; coding: A |
