Description
Reliable level detection through non-metallic vessel walls
Output function normally open / normally closed programmable
Particularly space-saving design for use where space is restricted
Easy installation with mounting adapters and cable ties
Clearly visible LED for switching status indication
Specification
Product characteristics
| Electrical design | NPN |
|---|---|
| Output function | normally closed |
| Sensing range[mm] [mm] | 4.7 |
| Housing | rectangular |
| Dimensions[mm] [mm] | 20 x 7 x 48 |
Application
| Application | level detection food and beverage industry |
|---|
Electrical data
| Operating voltage[V] [V] | 10...36 DC |
|---|---|
| Current consumption[mA] [mA] | < 30 |
| Protection class | III |
| Reverse polarity protection | no |
| Max. power-on delay time[ms] [ms] | 300 |
Outputs
| Electrical design | NPN |
|---|---|
| Output function | normally closed |
| Max. voltage drop switching output DC[V] [V] | 0.5 |
| Max. leakage current[mA] [mA] | 0.5 |
| Permanent current rating of switching output DC[mA] [mA] | 50 |
| Short-time current rating of switching output[mA] [mA] | 50 |
| Switching frequency DC[Hz] [Hz] | 10 |
| Short-circuit proof | no |
| Overload protection | no |
Detection zone
| Sensing range[mm] [mm] | 4.7 |
|---|
Accuracy / deviations
| Correction factor | glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 |
|---|---|
| Hysteresis[% of Sr] [% of Sr] | 1...15 |
| Switch point drift[% of Sr] [% of Sr] | -20...20 |
Operating conditions
| Ambient temperature[°C] [°C] | -25...80 |
|---|---|
| Protection | IP 65; IP 67 |
Tests / approvals
| EMC | EN 61000-4-2 8 kV AD EN 61000-4-3 3 V/m EN 61000-4-4 2 kV EN 61000-4-6 3 V EN 55011 class B |
|---|---|
| EN 61000-4-2 | 8 kV AD |
| EN 61000-4-3 | 3 V/m |
| EN 61000-4-4 | 2 kV |
| EN 61000-4-6 | 3 V |
| EN 55011 | class B |
| Shock resistance | EN 60947-5-2 |
| MTTF[years] [years] | 735 |
Mechanical data
| Weight[g] [g] | 32.6 |
|---|---|
| Housing | rectangular |
| Mounting | non-flush mountable |
| Dimensions[mm] [mm] | 20 x 7 x 48 |
| Materials | PBT; TPE-U; stainless steel |
Displays / operating elements
| Display | switching status 1 x LED, yellow |
|---|---|
| switching status | 1 x LED, yellow |
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| Cable | 0.4 m, PUR; 3 x 0.14 mm² |
|---|---|
| Connector | 1 x MOLEX |
