IFM EC3170
EC3170
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
With integrated amplifier
Robust design for use in mobile machines
Flat housing for roof mounting on vehicles and mobile machines
Quick and easy mounting and fixing
For a reliable signal transmission
Specification
Interfaces
| Frequency band | 2400...2483,5 MHz; 4900...5825 MHz |
|---|---|
| Connector type | SMA |
| Note on interfaces | Impedance: 50 Ohm Polarisation: linear noise density: 2 dBi |
| Transmission standard | LTE Cat-4 |
Operating conditions
| Ambient temperature[°C] [°C] | -40...85 |
|---|---|
| Protection | IP 67 |
Mechanical data
| Weight[g] [g] | 597.5 |
|---|---|
| Type of mounting | screw mounting |
| Dimensions[mm] [mm] | Ø 110 / L = 55 |
| Materials | ABS |
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection - GPS
| Cable | 3 m |
|---|---|
| Connector | 1 x SMA |
Electrical connection - Mobile networks
| Cable | 3 m |
|---|---|
| Connector | 2 x SMA |
Electrical connection - WLAN
| Cable | 3 m |
|---|---|
| Connector | 2 x SMA |
