IFM E3R110
E3R110
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Specification
Application
| Special feature | Drag chain suitability |
|---|---|
| Oil resistant | yes |
Electrical data
| Operating voltage[V] [V] | < 50 AC / < 60 DC |
|---|---|
| Protection class | III |
| Damping[dB/m] [dB/m] | 1.6 |
| Internal resistance (Ri)[Ω] [Ω] | 50; ( ± 3 Ω) |
Operating conditions
| Ambient temperature[°C] [°C] | -10...60 |
|---|---|
| Ambient temperature (moving)[°C] [°C] | -10...60 |
| Protection | IP 54 |
Mechanical data
| Weight[g] [g] | 340.4 |
|---|---|
| Materials | Cable: PUR black |
| Drag chain suitability | bending radius for flexible use 85 mm bending radius for fixed installation 60 mm bending radius 80 mm bending cycles 2.000.000 travel speed max. 4 m/s at 4 m horizontal travel length and max. acceleration of 8 m/s² |
| bending radius for flexible use | 85 mm |
| bending radius for fixed installation | 60 mm |
| bending radius | 80 mm |
| bending cycles | 2.000.000 |
| travel speed | max. 4 m/s at 4 m horizontal travel length and max. acceleration of 8 m/s² |
Accessories
| Accessory required | Adapter cable, E3R106 |
|---|
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| Connector | 2 x HF-Single, straight |
|---|
Electrical connection
| Cable | 5 m, black, Ø 5.6 mm |
|---|
