Description
Reliable protection against aggressive media and high flow velocities
Allows the replacement of the temperature sensor in a running process
High pressure rating
Simple process connection via adapter
Robust stainless steel housing for the requirements of harsh industrial environments
Specification
Application
| Design | for temperature sensors EL = 50 mm |
|---|---|
| Pressure rating | 100 bar 10 MPa |
| 100 bar | 10 MPa |
| Note on pressure rating | < 250 °C |
Mechanical data
| Weight[g] [g] | 84.9 |
|---|---|
| Materials | stainless steel (316Ti/1.4571) |
| Sensor connection | G 1/4 Ø 6 mm |
| Process connection | G 1/4 |
| Installation length EL[mm] [mm] | 27 |
| Bore length BL[mm] [mm] | 54 |
Remarks
| Pack quantity | 1 pcs. |
|---|
