IFM E12855
E12855
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Gold-plated contacts for reliable electrical connections
Wide operating temperature range
Good electromagnetic compatibility thanks to placeable cable shield
High protection rating for the requirements of the food and beverage industry
Specification
Application
| Special feature | Free from silicone; Gold-plated contacts |
|---|---|
| Design | D-coded |
| Free from silicone | yes |
Electrical data
| Operating voltage[V] [V] | < 250 AC/DC |
|---|---|
| Max. current load total[A] [A] | 4 |
Operating conditions
| Ambient temperature[°C] [°C] | -40...85 |
|---|---|
| Protection | IP 69 |
Mechanical data
| Weight[g] [g] | 57.2 |
|---|---|
| Dimensions[mm] [mm] | 20 x 20 x 62 |
| Materials | housing: stainless steel |
| Material nut | stainless steel |
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| screw terminals | ...0.75 mm²; Cable sheath: Ø 5.5...8.6 mm; AWG 18 |
|---|
Electrical connection - plug
| Connector | 1 x M12, straight; coding: D; Locking: stainless steel; Contacts: gold-plated; Shielded connection cable: shielded |
|---|
