IFM AC2619
AC2619
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Easy to mount and wire
For the connection of sensors and actuators with cable entry
Device connection with cage clamps
Clearly visible powerful LEDs for displaying operation, switching status and error
Specification
Application
| Application | field installation |
|---|
Electrical data
| Operating voltage[V] [V] | 26.5...31.6 DC |
|---|---|
| Max. current consumption from AS-i[mA] [mA] | 140 |
| Reverse polarity protection | yes |
| Additional voltage supply[V] [V] | 24...30 DC; (AUX) |
| Additional voltage supply | optional |
| Max. current consumption from additional supply[mA] [mA] | 550; (AUX) |
Inputs / outputs
| Number of inputs and outputs | Number of analogue outputs: 2 |
|---|
Inputs
| Precision analogue input[%] [%] | 0,5 |
|---|
Outputs
| Number of analogue outputs | 2; (connection of 2-wire or 4-wire actuators) |
|---|---|
| Analogue voltage output[V] [V] | 0...10 |
| Min. load resistance[Ω] [Ω] | 3300 |
| Overload protection | yes |
| Resolution of analogue output | 16 (1 bit = 1 mV) |
| Actuator supply outputs | AS-i / AUX |
Operating conditions
| Ambient temperature[°C] [°C] | 0...70 |
|---|---|
| Storage temperature[°C] [°C] | -25...85 |
| Max. relative air humidity[%] [%] | 90; (non condensing) |
| Max. height above sea level[m] [m] | 2000 |
| Protection | IP 65 |
Tests / approvals
| EMC | EN 50295 |
|---|---|
| MTTF[years] [years] | 145 |
AS-i classification
| AS-i master profile | M3; M4 |
|---|---|
| AS-i profile | S-7.3.5 |
| AS-i I/O configuration[hex] [hex] | 7 |
| AS-i ID code[hex] [hex] | 3.5 |
Mechanical data
| Weight[g] [g] | 296.5 |
|---|---|
| Housing | rectangular |
| Type of mounting | AS-i interface to FC-E lower parts |
| Dimensions[mm] [mm] | 102 x 91 x 71 |
| Materials | PBT |
Displays / operating elements
| Display | analogue signal LED, yellow channels AO1...AO2 operation LED, green AS-i, AUX errors LED, red |
|---|---|
| analogue signal | LED, yellow channels AO1...AO2 |
| operation | LED, green AS-i, AUX |
| errors | LED, red |
Electrical connection
| Module connection | Flat cables |
|---|
Remarks
| Pack quantity | 1 pcs. |
|---|
