Festo VMPAL-KMSK-V-SD25-IP67-5
For multi-pin plug connection Sub-D , Connecting cable between valve terminal MPA and controller , Variants suitable for energy chains , Pre-assembled at one end , Cable length 2.5 … 10 m , With PVC o…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
For multi-pin plug connection Sub-D , Connecting cable between valve terminal MPA and controller , Variants suitable for energy chains , Pre-assembled at one end , Cable length 2.5 … 10 m , With PVC or PUR cable , Ambient temperature -40 … +80 °C
Specification
| Product Weight |
1120 g |
|---|---|
| Electrical Connection |
Cable with plug |
| Cable Length |
5 m |
| Cable Characteristic |
Suitable for energy chains |
| Min. Cable Bending Radius |
63 mm |
| Cable Diameter |
12.5 mm |
| Cable Structure |
25 x 0.34 mm² |
| Degree Of Protection |
IP67, To IEC 60529 |
| Ambient Temperature With Moving Cable |
-5, 80 °C |
| Ce Mark (See Declaration Of Conformity) |
In accordance with EU RoHS Directive |
| Ukca Marking (See Declaration Of Conformity) |
To UK RoHS instructions |
| Labs (Pwis) Conformity |
VDMA24364-B1/B2-L |
| Note On Materials |
RoHS-compliant |
| Corrosion Resistance Class Crc |
2 – Moderate corrosion stress |
| Material Cable Sheath |
TPE-U(PU) |
