Festo VAVE-L1-1H2-LR
Electrical sub-base-VAVE-L1-1H2-LR
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Specification
| Reverse Polarity Protection | For operating voltage |
|---|---|
| Additional Functions | Spark arresting, Holding current reduction |
| Signal Status Display | LED |
| Nominal Operating Voltage Dc | 24 V |
| Immunity To Surge | 0.8 kV |
| Pollution Degree | 3 |
| Approval | RCM trademark |
| Ce Mark (See Declaration Of Conformity) | To EU EMC Directive |
| Ukca Marking (See Declaration Of Conformity) | To UK instructions for EMC |
| Corrosion Resistance Class Crc | 0 – No corrosion stress |
| Labs (Pwis) Conformity | VDMA24364-B1/B2-L |
| Degree Of Protection | IP40 |
| Ambient Temperature | -5, 60 °C |
| Mounting Position | optional |
| Product Weight | 1.5 g |
| Electrical Connection | 2-pin, Socket |
| Protective Conductor Connection | Not available |
| Type Of Mounting | Clip |
| Housing Colour | Black |
| Note On Materials | RoHS-compliant |
| Material Housing | PA |
