Festo NEFU-D12G4-R3DW4
Cable socket for branching the AS-Interface network at any required point , Reconnecting AS-Interface flat cable to 5-pin M12 socket , Reverse polarity protected
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Cable socket for branching the AS-Interface network at any required point , Reconnecting AS-Interface flat cable to 5-pin M12 socket , Reverse polarity protected
Specification
| Length |
40.1 mm |
|---|---|
| Conforms To Standard |
EN 61076-2-101, IEC 60603-7-3 |
| Type Of Mounting |
Screw-clamped |
| Electrical Connection 1 |
Straight socket, M12x1, 4-pin, D-coded |
| Electrical Connection 2 |
Angled socket, RJ45, 4-pin |
| Operational Voltage Range Dc |
30 V |
| Current Rating At 40° C |
2 A |
| Immunity To Surge |
0.8 kV |
| Transmission Characteristics |
In accordance with category 5, EN 50173, class D, In accordance with category 5, ISO/IEC 11801, class D |
| Degree Of Protection |
IP20, IP65, IP67 |
| Ambient Temperature |
-5, 60 °C |
| Labs (Pwis) Conformity |
VDMA24364-B2-L |
| Note On Materials |
RoHS-compliant |
| Pollution Degree |
3 |
| Corrosion Resistance Class Crc |
1 – Low corrosion stress |
| Material Housing |
Die-cast zinc |
| Housing Colour |
Black |
| Material Electrical Contact |
Brass, Bronze |
