Festo KPE-32
Ready-to-install combination of clamping cartridge KP and housing , Wide range of mounting options
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Ready-to-install combination of clamping cartridge KP and housing , Wide range of mounting options
Specification
| Mounting Position |
optional |
|---|---|
| Type Of Clamping With Direction Of Action |
on both sides, Clamping via spring force, released via compressed air |
| Design |
Tilting wedge mechanism |
| Variants |
Piston rod at one end |
| Position Detection |
Without |
| Safety Function |
Holding and stopping a movement |
| Operating Pressure |
43.5, 145 psi |
| Release Pressure |
3 bar |
| Round Material To Be Clamped |
32 mm |
| Operating Medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note On Operating And Pilot Medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion Resistance Class Crc |
2 – Moderate corrosion stress |
| Labs (Pwis) Conformity |
VDMA24364-B1/B2-L |
| Ambient Temperature |
-10, 80 °C |
| Static Holding Force |
7500 N |
| Product Weight |
4600 g |
| Release Connection, Clamping Unit |
G1/8 |
| Note On Materials |
RoHS-compliant |
| Material Seals |
NBR, TPE-U(PU) |
| Material Spring |
Spring steel |
| Material Housing |
Anodised |
| Material Clamp Jaws |
Brass |
| Material Piston |
POM |
