Danfoss (Drives) HB00A1
CYLINDER NZ B4.00 R1.75 S13.00 IN M11, NZ11HL2N1KW130RS-HB00A1 – HB00A1
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
CYLINDER NZ B4.00 R1.75 S13.00 IN M11, NZ11HL2N1KW130RS-HB00A1 – HB00A1
Specification
| Brand | Vickers by Danfoss |
|---|---|
| Bore Diameter | 4.00 inch |
| Mounting style | Cap spherical bearing |
| Rod material | Stainless Steel 17-4 |
| Port Type | Standard NPTF |
| Port Size | NPTF-0.750 |
| Cushion location | Cushion head 3 cap 3 |
| First rod end type | Short female UN thread |
| Gross stroke | 13.00 inch |
| Model Code 1 | NZ11HL2N1KW130RS-HB00A1 |
| Net stroke | 13.00 |
| Paint specification | Black flat enamel |
| Port location | Head 1 cap 1 |
| Rod end flats | 2 flats |
| Seal type | Normal |
| Series | NZ series-hydraulic 3000 psi |
| Test pressure PSI | 3000 |
| Working pressure PSI | 1750.00 |
