Danfoss (Drives) HA01K4
CYLINDER N5 B2.50 R1.00 S2.00 IN M19, N5H-2.50X2.00-N-1.00-2-S-H-R-3-3-HA01K4 – HA01K4
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
CYLINDER N5 B2.50 R1.00 S2.00 IN M19, N5H-2.50X2.00-N-1.00-2-S-H-R-3-3-HA01K4 – HA01K4
Specification
| Brand | Vickers by Danfoss |
|---|---|
| Bore Diameter | 2.50 inch |
| Mounting style | Centerline lug |
| Rod seal | Urethane Ultra-Seal |
| Piston seal | Cast Iron Rings |
| Port Type | SAE port |
| Port Size | SAE#10 |
| Head Port Location | Head port location 3 |
| Cap Port Location | Cap port location 4 |
| Cushion location | Non-cushioned |
| Customer part number | 5249078 |
| First rod end type | Male, small (standard) |
| Model Code 1 | N5H-2.50X2.00-N-1.00-2-S-H-R-3 |
| Model Code 2 | -3-HA01K4 |
| Net stroke length | 2.00 inch |
| Paint specification | Black paint |
| Rod flats | 2 flats |
| Series | N5 Series-Hydraulic |
| Stop tube IN | 0.00 |
| Sub brand | Hydro-Line |
| Test pressure PSI | 3000 |
| Working pressure PSI | 3000.00 |
