B&R X20EDS410-4G
B&R’s X20 Edge connects machine control with enterprise systems for enhanced production insight. Equipped with an ARM-based CPU and Linux OS, it provides flexible programming possibilities like Python…
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Description
B&R’s X20 Edge connects machine control with enterprise systems for enhanced production insight. Equipped with an ARM-based CPU and Linux OS, it provides flexible programming possibilities like Python and a containerized environment for deploying AI, machine learning and IIoT applications. Dual Ethernet ports and a 4G global modem open up communication possibilities like OPC UA and cloud connectivity, creating a seamless data flow between machines and IT infrastructure. Ideal as a smart IIoT gateway, the X20 Edge offers machine builders simplified integration of digital services, while end users gain access to advanced analytics – all in a compact, industrial-grade device.
Specification
| Interfaces |
1x USB 3.0, 2x Gigabit Ethernet |
|---|---|
| System module |
Edge controller |
| B&R ID code |
0x35A6 |
| Cooling |
Fanless |
| Status indicators |
Module status, network status |
| Module status |
Yes, using LED status indicator |
| Network status |
Yes, using LED status indicator |
| Power consumption |
9.6 W |
| CE |
In preparation |
| Input voltage |
24 VDC -20% / +25% SELV/PELV |
| Input current |
Max. 0.4 A |
| Fuse |
Integrated, cannot be replaced |
| Reverse polarity protection |
Yes |
| Software |
B&R-specific Debian image |
| Real-time clock |
Nonvolatile, ±20 ppm at 25°C |
| FPU |
Yes |
| Type |
Quectel EG21-GL LTE Cat 1 |
| Clock frequency |
1.6 GHz |
| Number of cores |
4 |
| Architecture |
64-bit |
| Data code |
32 kB |
| Program code |
32 kB |
| L2 cache |
512 kB |
| RAM |
4 GB LPDDR4 SDRAM |
| Data retention |
10 years (when new) to 1 year (end of service life) |
| Capacity |
64 GB |
| Lifetime monitoring |
Yes |
| MTBF |
>3,000,000 hours (at 25°C) |
| Writable data amount |
166 TB |
| Sequential reading |
100 MB/s |
| Sequential writing |
45 MB/s |
| Variant |
RP-SMA female |
| Line length |
Max. 100 m between 2 stations (segment length) |
| Transfer rate |
100 Mbit/s and 1 Gbit/s |
| Physical layer |
100BASE-TX/1000BASE-T |
| Half-duplex |
Yes |
| Full-duplex |
Yes |
| Autonegotiation |
Yes |
| Auto-MDI/MDIX |
Yes |
| Electrical isolation |
Ethernet isolated from each other and from power supply |
| Horizontal |
Yes |
| Vertical |
No |
| 0 to 2000 m |
No limitation |
| >2000 m |
Reduction of ambient temperature by 0.6°C per 100 m |
| Degree of protection per EN 60529 |
IP20 |
| Horizontal mounting orientation |
-25 to 60°C |
| Vertical mounting orientation |
Not permitted |
| Derating |
– |
| Storage |
5 to 95%, non-condensing |
| Transport |
5 to 95%, non-condensing |
| Operation |
5 to 95%, non-condensing |
| Width |
27.5 mm |
| Height |
124 mm |
| Depth |
92 mm |
| Weight |
165 g |
