B&R 8CM009.12-8
Motor cable, length 9 m, 4x 35 mm² + 2x (2x 1.5 mm²), not pre-assembled, can be used in cable drag chains
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Motor cable, length 9 m, 4x 35 mm² + 2x (2x 1.5 mm²), not pre-assembled, can be used in cable drag chains
Specification
| Cable cross section | 4x 35 mm² + 2x (2x 1.5 mm²) |
|---|---|
| Durability | Hydrolysis resistance per EN 50396 Halogen-free per EN 60754-1 PWIS per VW PV 3.10.7 Oil resistance per EN 60811-404 Flame propagation per EN 60332-1-2 |
| Certification | E170315 cRUus AWM STYLE 21209 VW-1 I/II A/B 90°C 1000 V FT1 |
| CE | Yes |
| UKCA | Yes |
| CRA (Cyber Resilience Act) | Not applicable |
| UL | cULus E225616 Power conversion equipment |
| Quantity | 4 |
| Wire insulation | PP |
| Wire colors | Black, labeled in white 5, 6, 7, 8 |
| Variant | Copper stranded wire |
| Cross section | 4x 1.5 mm² |
| Shield | Shielded in pairs, tinned copper braiding, optical coverage approx. 85% and foil shield |
| Stranding | No. 5+6, no. 7+8 |
| Cable stranding | With filler elements |
| Cable shield | Tinned copper braiding, optical coverage approx. 85% |
| Material | PUR |
| Color | Orange, similar to RAL 2003 flat |
| Labeling | 4x 35+ 2x (2x 1.5) C E170315 cRUus AWM STYLE 21209 VW-1 I/II A/B 90°C 1000 V FT1 |
| Operating voltage | Max. 1000 VAC (UL) |
| Wire - Wire | 4 kV |
| Wire - Shield | 4 kV |
| Current-carrying capacity | 35 mm²: 135 A 1.5 mm²: 18 A |
| Power lines | ≤0.554 Ω/km |
| Signal line | ≤13.3 Ω/km |
| Insulation resistance | ≥500 MΩ*km |
| Wall mounting | 133.77 A |
| Installed in conduit or cable duct | 116.48 A |
| Installed in cable tray | 143.78 A |
| Storage | -30°C to +90°C |
| Transport | -30°C to +90°C |
| Moving | ≥232.5 mm |
| Static | -50°C to +90°C |
| Length | 9 m |
| Diameter | 30.5 mm ±0.5 mm |
| Single bend | ≥124 mm |
| Acceleration | 50 m/s² up to 3 m travel path 15 m/s² up to 10 m travel path 5 m/s² up to 20 m travel path |
| Flex cycles | ≤10,000,000 |
| Velocity | ≤5 m/s |
| Weight | 17.51 kg |
