B&R 8BCM0005.3111A-0
ACOPOSmulti motor cable, length 5 m, 4x 1.5 mm² + 2x 2x 0.75 mm², 8-pin female speedtec motor connector size 1, integrated shield plate
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Description
ACOPOSmulti motor cable, length 5 m, 4x 1.5 mm² + 2x 2x 0.75 mm², 8-pin female speedtec motor connector size 1, integrated shield plate
Specification
| Cable cross section |
4x 1.5 mm² + 2x 2x 0.75 mm² |
|---|---|
| Durability |
Oil resistance TM5 per VDE 0281 Part 1 / HD21.1Flame resistance per IEC 60332-1-2 / UL 2556 (VW-1) / CSA C22.2 No. 2556 (FT-1) |
| CE |
Yes |
| UKCA |
Yes |
| CRA (Cyber Resilience Act) |
Not applicable |
| UL |
cULus E225616Power conversion equipment |
| Quantity |
4 |
| Wire insulation |
PP |
| Wire colors |
White, white/red, white/blue, white/green |
| Variant |
Tinned copper stranded wire |
| Cross section |
0.75 mm² |
| Shield |
Individually shielded in pairs, tinned copper braiding, optical coverage >85% and foil shield |
| Stranding |
White with white/red and white/blue with white/green |
| Cable stranding |
With filler elements and foil shield |
| Cable shield |
Tinned copper braiding, optical coverage >85% and foil shield |
| Material |
PVC |
| Color |
Orange, similar to RAL 2003 flat |
| Type |
8-pin female speedtec motor connector, size 1 |
| Mating cycles |
<500 |
| Contacts |
8 (4 power and 4 signal contacts) |
| Degree of protection per EN 60529 |
IP66/67 when connected |
| Wire - Wire |
4 kV |
| Wire - Shield |
3 kV |
| Power lines |
≤13.7 Ω/km |
| Signal line |
≤26.7 Ω/km |
| Insulation resistance |
≥100 MΩ*km |
| Wall mounting |
15.2 A |
| Installed in conduit or cable duct |
13.1 A |
| Installed in cable tray |
16.1 A |
| Moving |
≥190 mm |
| Static |
-20°C to +90°C |
| Length |
5 m |
| Diameter |
12.3 mm ±0.4 mm |
| Single bend |
>64 mm |
| Weight |
1.2 kg |
