B&R 8BCM0003.3034C-0
Motor cable, length 3 m, 4x 0.75 mm² + 2x 2x 0.34 mm², 8-pin female series 915 power connector
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Description
Motor cable, length 3 m, 4x 0.75 mm² + 2x 2x 0.34 mm², 8-pin female series 915 power connector
Specification
| Cable cross section |
4x 0.75 mm² + 2x 2x 0.34 mm² |
|---|---|
| Durability |
Oil resistance TM5 per VDE 0281 Part 1 / HD21.1Flame resistance per IEC 60332-1-2 / UL 2556 (VW-1) / CSA C22.2 No. 210.2 (FT-1) |
| Certification |
UL Style 2570 80°C 1000 V VW-1 E130266 and cUL AWM I/II A/B 80°C 1000 V FT-1 |
| CE |
Yes |
| UKCA |
Yes |
| CRA (Cyber Resilience Act) |
Not applicable |
| UL |
cULus E225616Power conversion equipment |
| Quantity |
4 |
| Wire insulation |
PP |
| Wire colors |
White, white/red, white/blue, white/green |
| Variant |
Tinned copper stranded wire |
| Cross section |
0.34 mm² |
| Shield |
Individually shielded in pairs, tinned copper braiding, optical coverage >85% and foil shield |
| Stranding |
White with white/red and white/blue with white/green |
| Cable stranding |
With filler elements and foil shield |
| Cable shield |
Tinned copper braiding, optical coverage >85% and foil shield |
| Material |
PVC |
| Color |
Orange, similar to RAL 2003 flat |
| Labeling |
B&R 4×0.75+2x2x0.34 XX/YYYY E130266 cURus AWM STYLE 2570 I/II A/B 80°C 1000 V FT-1 |
| Type |
8-pin female series 915 power connector |
| Mating cycles |
<500 |
| Contacts |
8 (4 power and 4 signal contacts) |
| Degree of protection per EN 60529 |
IP66/67 when connected |
| Wire - Wire |
4 kV |
| Wire - Shield |
3 kV |
| Power lines |
≤58.3 Ω/km |
| Signal line |
≤26.7 Ω/km |
| Insulation resistance |
≥100 MΩ*km |
| Wall mounting |
9.8 A |
| Installed in conduit or cable duct |
8.5 A |
| Installed in cable tray |
10.4 A |
| Moving |
≥165 mm |
| Static |
-20°C to +90°C |
| Length |
3 m |
| Diameter |
10.6 mm ±0.4 mm |
| Single bend |
>55 mm |
| Weight |
0.9 kg |
