B&R 5PC910.SX03-00
3-slot APC910 system unit
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
3-slot APC910 system unit
Specification
| LEDs | Power, HDD, Link, Run |
|---|---|
| B&R ID code | 0xD843 |
| Cooling | Passive via heat sink and optionally supported with an active fan kit |
| Type | SATA III (SATA 6.0 Gbit/s) |
| Service life | 4 years |
| Removable | Yes, accessible behind the front cover |
| Variant | DVI-I |
| Power button | Yes |
| Reset button | Yes |
| Buzzer | Yes |
| CE | Yes |
| UKCA | Yes |
| CRA (Cyber Resilience Act) | Evaluation ongoing |
| UL | cULus E115267 Industrial control equipment |
| Bootloader | BIOS |
| Battery-backed | Yes |
| Controller | Depends on the CPU board being used |
| Buffer time | 10 ms |
| Memory size | Depends on the CPU board being used |
| UART | 16550-compatible, 16-byte FIFO buffer |
| Max. baud rate | 1 Gbit/s |
| Quantity | 1 |
| Transfer rate | 10/100/1000 Mbit/s |
| Current-carrying capacity | Max. 1 A per connection |
| Version | Depends on the CPU variant used |
| Interface option | 2 |
| Monitor/Panel option | 1 |
| Add-on UPS slot | Yes |
| Slot for fan kit | Yes |
| Nominal voltage | 24 VDC ±25%, SELV |
| Nominal current | 5.5 A |
| Inrush current | Max. 60 A for < 300 μs |
| Overvoltage category per EN 61131-2 | II |
| Galvanic isolation | Yes |
| Pollution degree per EN 61131-2 | Pollution degree 2 |
| Degree of protection per EN 60529 | IP20 |
| Operation | -300 to 3000 m above sea level |
| Storage | 30 g, 6 ms |
| Transport | 30 g, 6 ms |
| Operation (continuous) | 2 to 9 Hz: 1.75 mm amplitude / 9 to 200 Hz: 0.5 g |
| Operation (occasional) | 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g |
| Material | Galvanized plate, plastic |
| Coating | Anthracite gray |
| Width | 151 mm |
| Height | 270 mm |
| Depth | 254.75 mm |
| Weight | 2650 g |
