B&R 5PC900.TS77-04
Intel Core i5-3610ME 2.7 GHzIntel QM77 chipset2x DDR3 memory socketIntel HD Graphics 4000AMI BIOS (UEFI)
CPU board Intel Core i5 3610ME 2…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Intel Core i5-3610ME 2.7 GHzIntel QM77 chipset2x DDR3 memory socketIntel HD Graphics 4000AMI BIOS (UEFI)
CPU board Intel Core i5 3610ME 2.7 GHz – Dual core – QM77 chipset – For APC910 – Product discontinued, not for use with new configurations
Specification
| CE | Yes |
|---|---|
| UKCA | Yes |
| UL | cULus E115267 Industrial control equipment |
| DNV | Temperature: B (0 to 55°C) Humidity: B (up to 100%) Vibration: A (0.7 g) EMC: B (bridge and open deck) |
| KR | Yes |
| Bootloader | Embedded AMI BIOS |
| Type | DDR3 |
| Clock frequency | 2700 MHz |
| Number of cores | 2 |
| Architecture | 22 nm |
| Thermal design power (TDP) | 35 W |
| Intel Smart Cache | 3 MB |
| External bus | DMI, 5 GT/s |
| Intel 64 architecture | Yes |
| Intel Turbo Boost Technology | 2.0 |
| Intel Hyper-Threading Technology | Yes |
| Intel vPro Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Chipset | Intel QM77 |
| Trusted Platform Module | No |
| Accuracy | At 25°C: Typ. 12 ppm (1 second) per day |
| Battery-backed | Yes |
| Number of memory channels | 2 |
| Memory size | Max. 16 GB |
| Max. memory bandwidth | 25.6 GB/s |
| Controller | Intel HD Graphics 4000 |
| Max. dynamic graphics frequency | 950 MHz |
| Color depth | Max. 32-bit |
| DirectX support | 11 |
| OpenGL support | 4.0 |
| DVI | Resolution up to 1920 x 1200 (WUXGA) |
| RGB | 350 MHz RAMDAC, resolution up to 2048 x 1536 @ 75 Hz (QXGA) |
| DisplayPort | Version 1.1 |
| Mass memory management | 4x SATA |
| Power management | ACPI 4.0 with battery support |
| Pollution degree per EN 61131-2 | Pollution degree 2 |
