B&R 5MP040.0381-01
3.8″ QVGA LCD m displayIntel PXA 270 processor51 system keysStop button2 integrated 3-position enable switches
Mobile Panel MP40, 3.8″ QV…
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Description
3.8″ QVGA LCD m displayIntel PXA 270 processor51 system keysStop button2 integrated 3-position enable switches
Mobile Panel MP40, 3.8″ QVGA LCD m display, Intel PXA 270 processor, 256 MB DRAM, 128 MB flash memory, ETH 10/100, USB 1.1, 51 system keys, stop button, 2 integrated 3-position enable switches, handle. Order cables and operating system separately.
Specification
| Reset button |
Yes |
|---|---|
| CE |
Yes |
| Type |
USB 1.1 |
| Clock frequency |
416 MHz |
| Mode/Node switches |
No |
| Controller |
SMSC11X |
| Size |
– |
| Battery-backed |
– |
| Diagonal |
3.8" (96.5 mm) |
| Colors |
16 shades of gray |
| Resolution |
QVGA, 320 x 240 pixels |
| Contrast |
20:1 |
| Horizontal |
Direction R / Direction L = 45° |
| Vertical |
Direction U = 30° / Direction D = 60° |
| Brightness |
110 cd/m² |
| Half-brightness time |
50,000 h |
| Technology |
– |
| Quantity |
1 |
| Variant |
Shielded RJ45 port |
| Transfer rate |
10/100 Mbit/s |
| Current-carrying capacity |
Max. 500 mA |
| Max. baud rate |
100 Mbit/s |
| Function keys |
No |
| Soft keys |
6 |
| System keys |
51 numeric keys, cursor block |
| 3-axis joystick |
No |
| Electronic handwheel |
No |
| Illuminated pushbutton |
No |
| Stop button |
Yes (2 normally closed contacts, right position) |
| Enable switch |
Yes (2 3-position buttons, left and right position) |
| Override potentiometer |
No |
| Key switch |
No |
| LEDs |
7 |
| Nominal voltage |
24 VDC ±25% (integrated reverse polarity protection) |
| Inrush current |
Max. 5.6 A (current limiting available) |
| Power consumption |
4.8 W (200 mA at 24 VDC) |
| Max. interruption of power supply |
≤10 ms |
| Galvanic isolation |
No |
| Drop height |
1.5 m to industrial floor |
| Flame-retardant |
UL 94 V-0 |
| Degree of protection per EN 60529 |
IP65 |
| Protection class |
Class 3 per EN 61131-2 and EN 50178 |
| Operation |
Max. 3000 m |
| Storage |
Max. 95%, non-condensing |
| Transport |
Max. 95%, non-condensing |
| Material |
Polyester |
| Coating |
Similar to RAL 7011 |
| Width |
252 mm |
| Height |
114 mm |
| Depth |
240 mm |
| Weight |
Approx. 1100 g |
