B&R 5MD900.USB2-02
Desktop or panel mount device (top-hat rail brackets)Integrated DVD-R/RW DVD+R/RW driveIntegrated IDE/ATAPI CompactFlash slot (hot pluggable)Integrated USB 2.0 connection+24 VDC power supply (back)USB…
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Description
Desktop or panel mount device (top-hat rail brackets)Integrated DVD-R/RW DVD+R/RW driveIntegrated IDE/ATAPI CompactFlash slot (hot pluggable)Integrated USB 2.0 connection+24 VDC power supply (back)USB 2.0 connection (back)Optional front cover
The USB media drive is equipped with a DVD-R/RW DVD+R/RW drive, CompactFlash slot and one USB interface on both the front and back. It is connected to a USB interface on the B&R industrial PC.
Specification
| Max. cable length |
5 m (without hub) |
|---|---|
| CE |
Yes |
| UKCA |
Yes |
| UL |
cULus E115267 |
| Type |
USB 2.0 |
| Connection |
IDE/ATAPI |
| Activity LED |
Signals read or write access to an inserted CompactFlash card |
| Variant |
Front: Type A |
| Transfer rate |
Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (480 Mbit/s) |
| Current-carrying capacity |
Max. 500 mA |
| Data buffer capacity |
2 MB |
| Data transfer rate |
Max. 33.3 MB/s |
| Speed |
Max. 5090 rpm ±1% |
| Noise level |
Approx. 45 dBA at a distance of 50 cm (full read access) |
| Compatible formats |
CD-DA, CD-ROM mode 1 / mode 2 |
| Laser class |
Class 1 laser |
| Service life |
60,000 POH (power-on hours) |
| Interface |
IDE (ATAPI) |
| CD |
Disk at once, session at once, packet write, track at once |
| DVD |
Disk at once, incremental, overwrite, sequential |
| CD-R |
10 to 24x |
| CD-RW |
10 to 24x |
| DVD+R |
3.3 to 8x |
| DVD+R (dual layer) |
2.4 to 4x |
| DVD+RW |
3.3 to 8x |
| DVD-R |
2 to 6x |
| DVD-R (dual layer) |
2 to 4x |
| DVD-RAM |
3 to 5x |
| DVD-RW |
2 to 6x |
| Nominal voltage |
24 VDC ±25%, SELV |
| Overvoltage category per EN 61131-2 |
II |
| Pollution degree per EN 61131-2 |
Pollution degree 2 |
| Degree of protection per EN 60529 |
Front: IP65 (only with optional front cover), back: IP20 |
| Operation |
Max. 3000 m |
| Storage |
60 g, 11 ms |
| Transport |
60 g, 11 ms |
| Width |
156 mm |
| Height |
52 mm |
| Depth |
140 mm |
| Weight |
Approx. 1100 g (without front cover) |
