B&R 5LS197.6
X2X Link connectionCAN bus interface
Logic scanner, PCI half-size module, 1 X2X Link master interface, electrically isolated, 1 CAN bus i…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
X2X Link connectionCAN bus interface
Logic scanner, PCI half-size module, 1 X2X Link master interface, electrically isolated, 1 CAN bus interface, electrically isolated, max. 500 kbit/s, object buffer in transmit and receive direction, 1 MB SRAM (Automation Runtime), order 3x 0TB704.9 terminal blocks separately!
Specification
| Communication module | 1x CAN bus, 1x X2X Link master |
|---|---|
| Ready relay | Normally open contact and normally closed contact, max. 30 VDC, max. 6 A |
| Status indicators | 1 LED per interface for transmitting data |
| Data transfer | Yes, using LED status indicator and software |
| Power consumption | 2.28 W |
| IF1 - IF2 | Yes |
| PC - IFx | Yes |
| CE | Yes |
| CRA (Cyber Resilience Act) | In preparation |
| UL | cULus E115267 Industrial control equipment |
| SRAM | 1 MB, battery-backed |
| Signal | CAN bus |
| Variant | 4-pin male multipoint connector |
| Max. distance | 1000 m |
| Transfer rate | Max. 500 kbit/s |
| Fieldbus | X2X Link master |
| Distance between 2 stations | Max. 100 m |
| Degree of protection per EN 60529 | IP20 in installed state |
| Operation | 5 to 95%, non-condensing |
| Storage | -25 to 70°C |
| Note | Order 3x 0TB704.9 terminal blocks separately Lithium battery included in delivery |
| Slot | Standard PCI half-size module, plug and play |
| B&R Automation PC | Yes |
| B&R Panel PC | Yes |
| Desktop PC | Yes |
