B&R 5CFCRD.8192-04
CompactFlash 8 GB B&R (SLC)
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Description
CompactFlash 8 GB B&R (SLC)
Specification
| Capacity |
8 GB |
|---|---|
| Data retention |
10 years |
| Data reliability |
<1 unrecoverable error per 1014 bits read |
| Lifetime monitoring |
Yes |
| MTBF |
>3,000,000 hours (at 25°C) |
| Servicing |
None |
| Supported operating modes |
PIO mode 0-6, Multiword DMA mode 0-4, Ultra DMA Mode 0-4 |
| Typical |
2,000,000 |
| Maximum |
17 MB/s |
| CE |
Yes |
| UKCA |
Yes |
| UL |
cULus E115267 |
| DNV |
Temperature: A (0 to 45°C) |
| SLC flash memory |
Yes |
| Guaranteed |
100,000 |
| Results for 5 years |
438.36 GB/day |
| Wear leveling |
Static |
| Error-correcting code (ECC) |
Yes |
| S.M.A.R.T. support |
No |
| Hardware |
PP300/400, PP500, PPC300, PPC700, PPC725, PPC800, APC620, APC810, APC820 |
| Windows 7 32-bit |
No |
| Windows 7 64-bit |
No |
| Windows Embedded Standard 7 32-bit |
Yes |
| Windows Embedded Standard 7 64-bit |
No |
| Windows XP Professional |
Yes |
| Windows XP Embedded |
Yes |
| Windows Embedded Standard 2009 |
Yes |
| Windows CE 6.0 |
Yes |
| Windows CE 5.0 |
No |
| PVI Transfer |
≥V3.2.3.8 (part of the PVI Development installer ≥ V2.06.00.3011) |
| B&R Embedded OS Installer |
≥V3.10 |
| Operation |
Max. 4,572 m |
| Storage |
1500 g peak, 0.5 ms 5 times (JEDEC JESD22, method B110) |
| Transport |
1500 g peak, 0.5 ms 5 times (JEDEC JESD22, method B110) |
| Width |
42.8 ±0.10 mm |
| Length |
36.4 ±0.15 mm |
| Height |
3.3 ±0.10 mm |
| Weight |
10 g |
