Banner Engineering LXTLV100X485HQ
LXT Series Laser Distance Measurement
Range: 200 mm – 100 m; 18-30 V dc
Modbus RTU; Heating Element
5-pin M12 Integral QD
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
LXT Series Laser Distance Measurement
Range: 200 mm – 100 m; 18-30 V dc
Modbus RTU; Heating Element
5-pin M12 Integral QD
Specification
| Power | DC |
|---|---|
| Pfm Output | No |
| Sensing Beam | Infrared Laser |
| Jam Detection | No |
| Pc Configurable | No |
| Ip Rating | IP65 |
| Nema / Ul Type Rating | NEMA 4X |
| Supply Voltage | 18-30 V dc |
| Item Status | RELEASED |
| Sensing Mode (General) | Single Point Optical |
| Sensing Mode (Detailed) | Wide Beam Retroreflective (Non-Polarized) |
| Housing Style | Rectangular |
| Device Type | Laser |
| Primary Housing Material | Aluminum Alloy Die-Cast |
| Laser Classification | Class 2 |
| Input/ Output | Serial (Modbus) |
| Connection | Integral QD |
| Quick Disconnect Type | M12 |
| Max Sensing Distance (Mm) | 10000 |
| Minimum Sensing Distance (Mm) | 200 |
| Number Of Pins | 5 |
| Discrete (Switched) Outputs | 1 NPN/PNP Configurable |
| Max Operating Temperature (C) | 50 |
| Min Operating Temperature (C) | -40 |
| Laser Control | No |
| Feature: Remote Teach | No |
| Feature: Washdown Rated | No |
| Feature: Clear Object Detection | No |
| Feature: Timing (Hold/Delay) | No |
| Feature: Chemical Resistant | No |
| Feature: Pump In/ Pump Out | No |
| Feature: Quick Disconnect | Yes |
| Feature: Health/Marginal Signal Output | No |
| Io Link | No |
| R S 232 | Yes |
